Açıklama
Özellikler
- 1.3 Megapixel Sony® Exmor™ sensor with 1000 TVL highest resolution (analog) and superior low light performance
- Tampering detection shows text in the image "Anti Blocking" or "Anti Shifting"
- Intelligent Video Content Analysis with Motion Tracking
- Smart IR LED Control with adjustable level
- 3 Axis Gimbal, 2 ways to mount: Wall/Ceiling Flat and Flush
- Remote Control Interfaces over Coax (Coaxitron)
- Built-in Service Monitor Port & OSD Control Port
- Support Dual Power AC24V/DC12V
Teknik Özellikler
- Image Sensor: 1/3" CMOS Sony Exmor® , 1.3 Megapixel
- Scanning System: PAL, 50Hz or NTSC, 60 HZ, selectable
- Pixels - Effective: 1302(H) x 1049(V), 1.3 Megapixels
- Resolution: 1000 (H) lines
- Col/B&W: Auto, Color, Removable IR-Cut Filter (ICR)
- Sensitivity Colour: 0.4 Lux(50IRE) @ F1.2 (SensUp=0, AGC Off), 0.0001Lux (50IRE) @ F1.2(AGC.Max., SensUpx64)
- Sensitivity B&W: 0 Lux LED IR on
- High Speed Shutter: 1/50 ~ 1/60.000 sec, auto, Antiflicker
- S/N Ratio: >50dB (AGC off)
- Lens Focal Length: 2.8 ~ 12 mm
- Horizontal Viewing Angle: 102° (Wide) ~ 27° (Tele)
- Lens Drive Type: Auto iris (DC)
- Iris F-Number: F= 1.2 ~ 360
- Sens Up: Off ~ x64 auto
- AGC: 0~20 adjustable, 15=default
- WDR: >=96dB
- De-Fog: Off/On Area Setting
- BLC Back Light: On/Off/HLC
- White Balance: ATW, AWB, AWC, Manual
- Digital Noise Reduction (DNR): 3D-DNR : Off/Low/Mid/High
- Digital Zoom: Off ~ 8x
- Motion Detection: On/ Off/ Sensitivity/ 4 Area setting
- Number of Privacy Zones: 16 programmable zones
- Intelligent Video Analytics: Scene change detection, masking of the camera lens
- Tampering Alarm: On/Off
- On Screen Alarm Information: On camera shaking: "Unknown Motion", on brightnes change "Blocking!!"
- Motion Tracking (Quick Zoom): On/Off
- Lens Shading Compensation: On/Off
- Reverse: Off/ H-REV/ V-REV
- OSD: Yes, E/D/F/I
- Profile Presets: Indoor, Outdoor, Elevator, Lobby, Low, High, Hallway
- IR LED: 28 pcs.
- Optical Wavelength: 850 nm
- Max. IR Distance: 15/30 m (according to scene reflexion)
- Remote Control: Coaxitron, data on coax cable
- Video Outputs: 1 Ch Composite BNC, 1 Test monitor 2-pin connector
- Alarm Outputs: 1
- Accessories included: Multi-Language Manual, Template, Cable for Service Monitor, Screws, screw driver for Zoom and Focus adjustment
- Protection Rating: IP67/IK10
- Humidity: less than 90%, non condensing
- Operating Temperature: -25°C ~ +55°C
- Supply Voltage: 12 Vdc / 24 Vac
- Power Consumption: 6 (LED on) W
- Weight: 1.03 kg
- Dimensions w*h*d: Ø 150 x 124 mm
