Açıklama

D-Link DGS 3120 48PC SI 10/100/1000 PoE Switch

Teknik Özellikler

Format & Standards
Network Management Type
Managed
Ports & Interface
Primary Ports
44 x RJ45 + 4 x SFP
Primary Port Speed
10/100/1000Mbps
Data Transmission
VLAN Support
Yes
Details
Buffer Memory
2MB
PoE
Yes
Stackable
Yes
SNMP
Yes
QoS
Yes
Layer
2
Power
100 to 240 VAC, 50 to 60 Hz Internal Universal Power Supply
Features
Switching Capacity: 136 Gbps
64-Byte Packet Forwarding Rate: 101.19 Mbps
Flash Memory: 32 MB
Console Port: RJ-45
Stacking Port: 2
SD Card Slot: 1
Standard Image (SI) Features:
Stackability: Physical Stacking, Virtual Stacking
L2 Features:
Flow Control
Spanning Tree Protocols
Loopback Detection
802.3ad Link Aggregation
L2 Multicasting:
IGMP Snooping
Limited IP Multicast
MLD Snooping
VLAN:
VLAN Group -Max. 4K VLAN Groups
GVRP -Max. 255 Dynamic VLAN Groups
802.1Q Tagged VLAN
Port-based VLAN
802.1v Protocol VLAN
Voice VLAN
MAC-based VLAN
ISM VLAN
Asymmetric VLAN
Private VLAN
VLAN Trunking
Security:
SSH v2
SSL v1/v2/v3
Port Security -Up to 64 MAC addresses per port/VLAN
Broadcast/Multicast/Unicast Storm Control
Traffic Segmentation
D-Link Safeguard Engine
NetBIOS/NetBEUI Filtering
DHCP Server Screening
ARP Spoofing Prevention
BPDU Attack Protection
Management:
Web-based GUI (Supports IPv4)
Command Line Interface (CLI)
Telnet Server(Supports IPv4)
Telnet Client(Supports IPv4)
TFTP Client(Supports IPv4)
ZModem
SNMP v1/v2c/v3
SNMP Traps
System Log (Supports IPv4 Log Server)
RMON v1: Supports 1,2,3,9 groups
RMON v2: Supports ProbeConfig group
LLDP
BootP/DHCP Client
DHCP Auto-Configuration
DHCP Relay
DHCP Relay Option 12
DHCP Relay Option 82
Flash File System
Multiple Images
Multiple Configurations
CPU Monitoring
Debug Command
SNTP
Password Recovery
Password Encryption
Trusted Host
Microsoft NLB (Network Load Balancing) Support
Dimensions & Weight
Dimensions
17.3" x 14.96" x 1.73"
Weight
13.96 lbs.



pdfD-Link DGS 3120 48PC SI 10/100/1000 PoE Switch Pdf Dosyası702.35 KB

Teknik Kısa

PoE : PoE
Port Hızı : 1 GBit
Yönetilebilirlik : Yönetilebilir Layer 3
Aktarım Port Sayısı : 4
Aktarım Türü : Combo
PoE Port Sayısı : Tooltip 44 Port
PoE Güç Bütçesi : 400-800 Watt
