| Görüntü Sensörü | 1/3" Interline Transfer CCD |
| Sensing area | 1/3" format (4.8 x 3.6mm) |
| Scanning System | 625 Lines 50 Fields/25 Frames, 2:1Interlace |
| Picture Elements | 752(H) x 582(V) |
| Signal System | CCIR standard |
| Synchronisation | Line Lock |
| V-Phase Control | ±90° |
| Video Signal | 1.0 V peak to peak at 75 Ohms, sync negative |
| Yatay Çözünürlük | 570 TV lines |
| Signal/Noise | Better than 50 dB (AGC OFF, Weight ON) |
| Minimum Aydınlatma | 0.04 lx at F1.2 (30 IRE, AGC ON) |
| 0.07 lx at F1.2 (50 IRE, AGC ON) |
| 0.3 lx at F1.2 (100 IRE, AGC ON) |
| AGC | ON (Turbo AGC) / OFF switchable |
| CCD Iris | ON/OFF switchable:1/50 to 1/100,000 second |
| Auto Iris Lens | DC / VIDEO servo switchable |
| Iris Level Control | Variable |
| BLC | ON(Centre measured)/OFF switchable |
| Lens mount | CS mount (C mount is mountable by using adapter) |
| Güç Gereksinimi | 220-240VAC±10%, 50Hz |
| Güç Tüketimi | 2.6 Watts (AC220V) |
| Boyutlar | 60(W) x 54(H) x 120(D) (mm) (2 3/8 x 2 1/4 x 4 3/4 inches) |
| Mass | 390g (14 oz) |
| Çalışma Sıcaklığı | -10°C to + 50°C (14°F to 122°F) |
| Çalışma Nemi | 20% to 80%, Non-condensing |
