| System |
| Time Accuracy : 5ppm (12.5sec/month) |
| Time Sync. : NTP, GMT, DST, Time Server |
| User : 15 Users (Admin., User1 ~ User14) |
| Video |
| Input : 8 BNC |
| Output : 1 HDMI, 1 VGA, 1 BNC |
| Loop : N/A |
| Spot : 1 BNC - Multi-channel (16/9/4/1) |
| Audio |
| Input : 8 RCA |
| Output : HDMI, RCA |
| Video Recording |
| Resolution : AHD: 720P, 960H: 960H,D1,CIF |
| Quality : 5 Levels |
| Audio Recording |
| Compression : G.711U |
| Network |
| Interface : Ethernet 10/100/1G |
| Compression : H.264 |
| Speed : Max. 720P 10fps/ch |
| Resolution : Max. 720P |
| Alarm |
| Pre/Post-Alarm : 5sec / 5sec~5min |
| Motion Grid : 14 x 15 (NTSC/PAL) |
| Input / Output : 4/1, 4/1, 4/1 - NC/NO/EOL |
| Display |
| HDMI : Full HD, XGA |
| VGA : Full HD, XGA |
| TV : SDTV(720x480/576) |
| External Interface |
| PTZ / Keyboard : 2 RS485 - Terminal Block |
| ATM / POS : RS232C - Terminal Block, Ethernet POS |
| Storage |
| Primary, External : 2 HDD (or 1HDD & 1 eSATA) |
| General |
| OS : Embedded Linux |
| Dimension : 340 x 59 x 300 mm |
| Net Weight(w/o HDD) : 3Kg |
| Power Supply : 12V/5A - Level 5 |
| Consumption : 60Watts |
| Operating Temp : 5 ~ 40˚C |
| Humidity : 10 ~ 80% |
