| Video |
| Max Channel : 32 IP Channel |
| Max Streaming Rate : Max 120fps @ Full-HD |
| Compression : H.264 / MJPEG |
| Supported Resolution : All of FlexWATCH IP Camera Resolution [ ~Full-HD (1920x1080) ] |
| Streaming Function : Retransmission (Proxy) |
| Output : 1 HDMI / 1 VGA |
| Recording |
| Max Recording Rate : Max 480fps @ Full-HD |
| Rcording Stream : Video / Audio / Data |
| HDD : 4 SATA HDDs up to 6TB / each ( Max. 24TB ) |
| Recording Condition : Always, Motion, Event, Schedule |
| Audio |
| Encoding : 8bit G.711, 8khz, 8Kbyte/sec |
| Interface |
| PTZ Support : Remote PTZ Control |
| Alarm Input/Output : 4DI, 1DO |
| Serial Port : RS-232C, RS-485 |
| USB : 2 x USB 2.0 / 1 x USB 3.0 |
| Network |
| LAN Interface(RJ-45) : 10/100/1000-base-T Ethernet (auto sensing) |
| Protocol : HTTP, TCP/IP, UDP, FTP, Telnet, RARP, PPPoE, PAP, CHAP, DHCP, NTP, SMTP client, uPNP and etc. |
| Web Viewer : Browser (IE, Firefox, Safari etc), CMS, Quick Time, VLC |
| Search & Play : Browser (IE, Firefox, Safari etc), CMS |
| Key Function |
| Remote Admin : Web based administration, setup, control and upgrade |
| Advanced Service : E-mail notification |
| Dynamic IP : DDNS / uPNP Support |
| Motion Detection : Motion recording |
| Security : Encrypted & Basic Authentication |
| Hardware |
| 19" RACK : 19" 1U standard Rack |
| Certification : KC, FCC, CE, RoHS, UL |
| Condition : 0℃ ~ +50℃ (32℉ ~ 122℉), 10% ~ 80% RH |
| Power Supply : Input : 100-240VAC, 50~60Hz Output : SMPS, 12VDC @ 7A Power Consumption : Max. 40W |
| Size/Weight |
| Size : 430(W) x 420(D) x 45(H) (in mm) Weight : About 5,500g without HDD |
