| Video/Audio Input |
| IP video input : 32-ch |
| Two-way audio input : 1-ch, RCA (2.0 Vp-p, 1kΩ) |
| Network |
| Incoming bandwidth : 160Mbps |
| Outgoing bandwidth : 80Mbps |
| Remote connection : 128 |
| Video/Audio Output |
| HDMI/VGA output : 1-ch, resolution:1920 × 1080P /60Hz, 1600 × 1200 /60Hz, 1280 × 1024 /60Hz, 1280 × 720 /60Hz,1024 × 768 /60Hz |
| Recording Resolution : 6MP/5MP/3MP/1080P/UXGA/720P/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
| Frame Rate : Main stream: 50 fps (P) / 60 fps (N) |
| Sub-stream : 50 fps (P) / 60 fps (N) |
| Audio Output : 1-ch, RCA (Linear, 1kΩ) |
| Decoding |
| Live view / Playback : 6MP/5MP/3MP/1080P/UXGA/720P/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
| Capability : 16-ch @ 4CIF, 12-ch @ 720P, 6-ch @ 1080P |
| Hard Disk |
| SATA : 4 SATA interfaces for 2 HDDs + 1 DVD-R/W (default), or 4HDDs |
| Capacity : Up to 6TB capacity for each HDD |
| External Interface |
| Network Interface : 2 RJ-45 10/100/1000Mbps self-adaptive Ethernet interfaces |
| Serial Interface : RS-232; RS-485; |
| USB Interface : Front panel: 2 × USB 2.0 |
| Rear panel : 1 × USB 3.0 |
| Alarm In : 16-ch |
| Alarm Out : 4-ch |
| General |
| Power Supply : 100~240VAC |
| Consumption(without hard disk and POE) : ≤ 20W |
| Working Temperature : -10 ºC ~ +55 ºC (+14 ºF~ + 131 ºF) |
| Working Humidity : 10 % ~ 90 % |
| Chassis : 19-inch rack-mounted 1.5U chassis |
| Dimensions : 445 × 390 × 70mm (17.5 ×15.3 × 2.8 inch) |
| Weight(without HDD) : ≤ 4 Kg (8.82 lb) |
