| Video/Audio Input |
| Two-way audio input |
1-ch, RCA (2.0 Vp-p, 1kΩ) |
| IP video input |
32-ch |
| Network |
| Remote connection |
128 |
| Incoming bandwidth |
256Mbps |
| Outgoing bandwidth |
160Mbps |
| Video/Audio Output |
| HDMI Output |
1-ch, resolution: 4K(3840*2160)/60Hz, 4K(3840*2160)/30Hz, 1920*1080P/60Hz, 1600*1200/60Hz, 1280*1024/60Hz, 1280*720/60Hz, 1024*768/60Hz |
| Recording Resolution |
8MP/6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
| Audio Output |
1-ch, RCA (Linear, 1kΩ) |
| Synchronous Playback |
16-ch |
| VGA Output |
1-ch, resolution: 1920*1080P/60Hz, 1280*1024/60Hz, 1280*720/60Hz, 1024*768/60Hz |
| Decoding |
| Capability |
8-ch@1080P |
| Live view / Playback |
8MP/6MP/5MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
| Hard Disk |
| SATA |
4 SATA interfaces for 4HDDs |
| Capacity |
Up to 6TB capacity for each HDD |
| External Interface |
| Network Interface |
2 RJ-45 10/100/1000Mbps self-adaptive Ethernet interfaces |
| Serial Interface |
RS-232; RS-485; |
| USB Interface |
Front panel: 2 × USB 2.0 |
| Rear panel: 1 × USB 3.0 |
| Alarm In |
16-ch |
| Alarm Out |
4-ch |
| General |
| Power Supply |
100 to 240 VAC |
| Consumption(without hard disk and POE) |
≤20 W |
| Working Temperature |
-10 oC ~ +55 oC (+14 oF~ + 131 oF) |
| Working Humidity |
10 % ~ 90 % |
| Chassis |
19-inch rack-mounted 1.5U chassis |
| Dimensions |
445 × 390 × 70 mm (17.5"× 15.3" × 2.8") |
| Weight(without HDD) |
≤ 5 Kg (11 lb) |
