| Video/Audio Input |
| IP Video Input | 32-ch |
| Two-way Audio Input | 1-ch, BNC |
| Network |
| Incoming Bandwidth | 384Mbps |
| Outgoing Bandwidth | 384Mbps |
| Remote Users | 128 |
| Video/Audio Output |
| HDMI/VGA Output | VGA: |
| 1920x1080p /60Hz, 1920x1080p /50Hz, 1600x1200 /60Hz, 1280x1024 /60Hz, 1280x720 /60Hz, 1024x768 /60Hz |
| HDMI1： |
| 4K (3840x2160) /30Hz, 1920x1080p /60Hz, 1920x1080p /50Hz, 1600x1200 /60Hz, 1280x1024 /60Hz, 1280x720 /60Hz, 1024x768 /60Hz |
| HDMI2: |
| 4K (3840x2160) /30Hz, 1920x1080p /60Hz, 1920x1080p /50Hz, 1600x1200 /60Hz, 1280x1024 /60Hz, 1280x720 /60Hz, 1024x768 /60Hz |
| Recording Resolution | 12MP/8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF |
| Audio Output | 1-ch, BNC |
| Synchronous Playback | 16-ch |
| Decoding |
| Compression | H.265/H.264 |
| Live view/Playback | 12MP/8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF |
| Capability | 4 x 12MP@20, 4 x 4K@30, 16 x 1080p@30, 36 x 720p@30, 64 x D1 |
| Hard Disk |
| SATA | 16 SATA interfaces |
| Capacity | up to 8TB for each HDD |
| eSATA | 1 eSATA interface |
| miniSAS | 2 miniSAS ports |
| Disk Array |
| Array Type | RAID 0/1/5/6/10/50/60 |
| External Interface |
| Network Interface | 4 RJ-45 10M/100M/1000M adaptive Ethernet Interface |
| 2 1000M SFP Ethernet Interface |
| Serial Interface | 1 x RS232, 1 x RS485 |
| USB Interface | Rear panel: 4 x USB3.0 |
| Alarm In | 24-ch |
| Alarm Out | 8-ch |
| Decoding Card (optional) | 2 slots (4-ch HDMI or 6-ch HDMI outputs per card) |
| Power Output | 12V |
| General |
| Power Supply | 100 ~ 240V AC |
| Consumption | ≤ 50 W |
| Working Temperature | -10°C ~ + 55°C ( +14°F ~ +131°F ) |
| Working Humidity | 10% ~ 90% |
| Chassis | 19-inch rack-mounted 3U chassis |
| Dimensions | 131mm × 482mm ×477mm ( 5.1" × 19.0" × 18.8" ) |
| Weight ( without HDD ) | ≤ 10 Kg ( 22.05 lb ) |
