| Video/Audio Input |
| IP Video Input | 8-ch |
| Two-way Audio Input | 1-ch, RCA |
| Network |
| Incoming bandwidth | 48Mbps |
| Outgoing bandwidth | 48Mbps |
| Remote Users | 128 |
| Video/Audio Output |
| HDMI/VGA Output | HDMI: |
| 4K (3840x2160) /30Hz, 1920x1080p /60Hz, 1920x1080p /50Hz, 1600x1200 /60Hz, 1280x1024 /60Hz, 1280x720 /60Hz, 1024x768 /60Hz |
| VGA: |
| 1920x1080p /60Hz, 1920x1080p /50Hz, 1600x1200 /60Hz, 1280x1024 /60Hz, 1280x720 /60Hz, 1024x768 /60Hz |
| Audio Output | 1-ch, RCA |
| Recording Resolution | 8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF |
| Synchronous Playback | 8-ch |
| Decoding |
| Compression | H.265/H.264 |
| Live view/ Playback | 8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF |
| Capability | 1 x 4K@30, 1 x 6MP@30,1 x 5MP@30, 2 x 4MP@30, 4 x 1080p@30, 8 x 720p@30 |
| Hard Disk |
| SATA | 2 SATA interface |
| Capacity | up to 8TB for each disk |
| External Interface |
| Network Interface | 1 RJ-45 10M/100M self-adaptive Ethernet Interface |
| USB Interface | Rear panel：2 x USB2.0, Front panel：1 x USB2.0 |
| Alarm In | 4-ch |
| Alarm Out | 1-ch |
| General |
| Power Supply | 12V DC |
| Consumption ( without HDD ) | ≤ 5 W |
| Working Temperature | -10°C ~ + 55°C ( +14°F ~ +131°F ) |
| Working Humidity | 10% ~ 90% |
| Dimensions | 46mm × 315mm × 380mm ( 1.8" × 12.4" × 15.0" ) |
| Weight ( without HDD ) | ≤ 2.18 Kg (4.81 lb ) |
