| Video/Audio Input |
| IP video input: | 8-ch |
| Two-way audio input: | 1-ch, RCA (2.0 Vp-p, 1kΩ) |
| Network |
| Outgoing bandwidth: | 40Mbps |
| Video/Audio Output |
| HDMI/VGA output: | 1-ch, resolution: |
| | 1920 × 1080P /60Hz, 1280 × 1024 /60Hz, 1280 × 720 /60Hz, 1024 × 768 /60Hz |
| Frame Rate: | Main stream: 50 fps (P) / 60 fps (N) |
| | Sub-stream: 50 fps (P) / 60 fps (N) |
| Audio Output: | 1-ch, RCA (Linear, 1kΩ) |
| Decoding |
| Capability: | 4-ch@1080P |
| Hard Disk |
| SATA: | 1 SATA interface for 1 HDD |
| Capacity: | Up to 6TB capacity for each HDD |
| External Interface |
| Network Interface: | 1 RJ-45 10 / 100 Mbps selfadaptive |
| | Ethernet interface |
| USB Interface: | 2, USB2.0 |
| General |
| Power Supply: | 12 VDC |
| Consumption(without hard disk and POE): | ≤ 18 W |
| Working Temperature: | -10 ºC ~ +55 ºC (+14 ºF~ + 131 ºF) |
| Working Humidity: | 10 % ~ 90 % |
| Dimensions: | 200 × 205 × 48 mm (7.9" × 8.1" × 1.9") |
| Weight(without HDD): | ≤ 1 kg (2.2 lb) |
