D-Link DGS 3120 24PC SI 10/100/1000 PoE Switch
Teknik Özellikler
| Format & Standards |
| Network Management Type |
| Managed |
| Ports & Interface |
| Primary Ports |
| 20 x RJ45 + 4 x SFP |
| Primary Port Speed |
| 10/100/1000Mbps |
| Data Transmission |
| MAC Address Table |
| 16K |
| VLAN Support |
| Yes |
| Jumbo Frames |
| Up to 13K Bytes |
| Details |
| Buffer Memory |
| 2MB |
| PoE |
| Yes |
| Stackable |
| Yes |
| SNMP |
| Yes |
| QoS |
| Yes |
| Layer |
| 2 |
| Port Mirroring |
| Yes |
| Power |
| 100 to 240 VAC, 50 to 60 Hz Internal Universal Power Supply |
| Features |
| Switching Capacity: 88 Gbps |
| 64-Byte Packet Forwarding Rate: 65.48 Mpps |
| Flash Memory: 32 MB |
| Console Port: RJ-45 |
| Stacking Port: 2 |
| SD Card Slot: 1 |
| Standard Image (SI) Features: |
| Stackability: Physical Stacking, Virtual Stacking |
| L2 Features: |
| Flow Control |
| Spanning Tree Protocols |
| Loopback Detection |
| 802.3ad Link Aggregation |
| L2 Multicasting: |
| IGMP Snooping |
| Limited IP Multicast |
| MLD Snooping |
| VLAN: |
| VLAN Group -Max. 4K VLAN Groups |
| GVRP -Max. 255 Dynamic VLAN Groups |
| 802.1Q Tagged VLAN |
| Port-based VLAN |
| 802.1v Protocol VLAN |
| Voice VLAN |
| MAC-based VLAN |
| ISM VLAN |
| Asymmetric VLAN |
| Private VLAN |
| VLAN Trunking |
| Security: |
| SSH v2 |
| SSL v1/v2/v3 |
| Port Security -Up to 64 MAC addresses per port/VLAN |
| Broadcast/Multicast/Unicast Storm Control |
| Traffic Segmentation |
| D-Link Safeguard Engine |
| NetBIOS/NetBEUI Filtering |
| DHCP Server Screening |
| ARP Spoofing Prevention |
| BPDU Attack Protection |
| Management: |
| Web-based GUI (Supports IPv4) |
| Command Line Interface (CLI) |
| Telnet Server(Supports IPv4) |
| Telnet Client(Supports IPv4) |
| TFTP Client(Supports IPv4) |
| ZModem |
| SNMP v1/v2c/v3 |
| SNMP Traps |
| System Log (Supports IPv4 Log Server) |
| RMON v1: Supports 1,2,3,9 groups |
| RMON v2: Supports ProbeConfig group |
| LLDP |
| BootP/DHCP Client |
| DHCP Auto-Configuration |
| DHCP Relay |
| DHCP Relay Option 12 |
| DHCP Relay Option 82 |
| Flash File System |
| Multiple Images |
| Multiple Configurations |
| CPU Monitoring |
| Debug Command |
| SNTP |
| Password Recovery |
| Password Encryption |
| Trusted Host |
| Microsoft NLB (Network Load Balancing) Support |
| Dimensions |
| 17.3" x 12.2" x 1.73" |
| Weight |
| 11.95 lbs. |
| Environmental |
| Temperature |
| ºC to 50ºC (32ºF to 122ºF) |
| Humidity |
| 10% - 90%, Non-condensing |
D-Link DGS 3120 24PC SI 10/100/1000 PoE Switch Pdf Dosyası702.35 KB
Teknik Kısa
PoE : PoE
Port Hızı : 1 GBit
Yönetilebilirlik : Yönetilebilir Layer 2
Aktarım Port Sayısı : 4
Aktarım Türü : Gbit Fiber
PoE Port Sayısı :
24 Port
24 Port PoE Güç Bütçesi : 200-400 Watt
