Edge-corE ECS2020-28P PoE Switch
Özellikler
- Support 2/4 integrated Gigabit SFP ports. Besides providing more uplink bandwidth, the SFP ports can be used for redundant links.
- Operate at a temperature from 0-50ºC.
- Supports automatic voice/surveillance VLANs, providing VoIP and IP cameras the optimum network traffic usage.
- 4KV Surge Protection
- IGMP/MLD snooping manages multicast streams to ensure high-quality, smooth video.
- Support
Teknik Özellikler
| Port | |
| RJ-45 10/100/1000 Ports | 24 |
| 100/1000 SFP Ports | 4 (1G) |
| PoE Ports | 24 |
| Console Port | no |
| Performance | |
| Switching Capability | 56 Gbps |
| Forwarding Rate | 41.7 Mpps |
| Flash Memory | 16MB |
| DRAM | 128MB |
| MTBF | 83.923hrs |
| Packet Buffer | 4.1 Mbits |
| MAC Address Table | 8K |
| Jumbo Frames | 10K |
| Heat Dissipation | 657.87 (Btu/H) |
| Acoustic Noise | <40 dB |
| Power Supply | |
| 100-240VAC, 50-60Hz | yes |
| Max. System Power Consumption (Watts) | 210.2W |
| PoE | |
| IEEE 802.3af/802.3at | yes |
| PoE Power Budget | 190W |
| PoE Timer | yes |
| Environmental | |
| Operating Temperature | 0-50°C |
| Storage Temperature | -40 - 70°C |
| Operating Humidity (non-condensing) | 10% to 90% |
| Storage Temperature (non-condensing) | 10% to 90% |
| Altitude | 3000m |
| Certification | |
| CE/FCC | YES |
| UL/BSMI | YES |
| Safety Compliance :CB | YES |
Teknik Kısa
PoE : PoE
Port Hızı : 1 GBit
Yönetilebilirlik : Yönetilebilir Layer 2
Aktarım Port Sayısı : 4
Aktarım Türü : Gbit Fiber
PoE Port Sayısı :
24 Port
24 Port PoE Güç Bütçesi : 130-200 Watt
