| 10G RJ45 Ports | 2 x 10GBASE-T (Fast Ethernet, 1G and 10G speeds) |
| 10G Fiber SFP+ Ports | 2 x SFP+ (1G and 10G speeds) |
| Power over Ethernet | 48 x PoE+ 30W |
| PoE Budget (Watts) | 591W PoE Budget with 1 PSU @ 110V AC input |
| 591W PoE Budget with 2 PSUs in redundant RPS mode @ 110V AC input |
| 1,010W PoE Budget with 2 PSUs in shared EPS mode @ 110V AC input |
| 860W PoE Budget with 1 PSU @ 220V AC input |
| 860W PoE Budget with 2 PSUs in redundant RPS mode @ 220V AC input |
| 1,440W PoE Budget with 2 PSUs in shared EPS mode @ 220V AC input |
| External RPS4000v2 for power redundancy (RPS) when 2 internal PSUs are used in EPS mode |
| Feature Set | Layer 3 (static, policy-based and RIP OSPF VRRP PIM dynamic routing) |
| Management Ports | 1G Ethernet service port for out-of-band management (OOB, RJ45) |
| RS232 straight-through serial RJ45 for local management console |
| Mini-USB port for local management console |
| USB port for local storage, logs, configuration or image files |
| Form Factor | Full width with dual, redundant modular PSUs for business continuity |
