D-Link DGS 1005P PoE Switch
Teknik Özellikler
| Interfaces |
| • 5 10/100/1000Base-T ports (ports 1 to 4 support PoE) |
| Standards |
| • IEEE 802.3 10Base-T Ethernet |
| • IEEE 802.3u 100Base-TX Fast Ethernet |
| • IEEE 802.3ab 1000Base-T Gigabit Ethernet |
| • IEEE 802.3x Flow Control |
| • IEEE 802.3az Energy Efficient Ethernet (EEE) |
| • ANSI/IEEE 802.3 NWay auto-negotiation |
| • IEEE 802.3af Power over Ethernet |
| • IEEE 802.3at Power over Ethernet |
| • Auto-MDI/MDI-X adjustment on all ports |
| • IEEE 802.1p QoS (8 queues) |
| Switching Capacity |
| • 10 Gbps switching fabric |
| Transmission Method |
| • Store-and-forward |
| Packet Filtering / Forwarding Rates |
| • 7.44 Mpps |
| MAC Address Table |
| • 2K entries per device |
| RAM Buffer |
| • 192 KB |
| Jumbo Frame Size |
| • 9,216 bytes |
| Flash Memory Size |
| • 1 KB |
| Diagnostic LEDs |
| • Power |
| • Link/Activity/Speed (per port) |
| • PoE OK/PoE Fail (per PoE port) |
| • PoE Max |
| PoE Power Budget |
| • 60 W (30 W max. per PoE port) |
| Physical Parameters |
| Weight |
| • 0.26 kg |
| Dimensions |
| • 100 x 98 x 28 mm |
| DC Input |
| • External 53.5 V / 1.2 A power adapter |
| Maximum Power Consumption |
| • 64.5 W (PoE on) |
| • 3.08 W maximum (PoE off) |
| Standby Power Consumption |
| • 0.54 W |
| MTBF |
| • 277,899 hours |
| Heat Dissipation |
| • 220.08 BTU/hr |
| Acoustics |
| • 0 dB |
| Ventilation System |
| • Fanless |
| Temperature |
| • Operating: 0В° to 40В°C |
| • Storage: -10В° to 70В°C |
| Humidity |
| • Operating: 0 to 95% non-condensing |
| • Storage: 0% to 95% non-condensing |
| EMI/EMC |
| • CE |
| • BSMI |
| • FCC |
| • VCCI |
| • RCM |
| Safety |
| • cUL |
| • CB |
| • LVD |
| • BSMI |
Teknik Kısa
PoE : PoE
Port Hızı : 1 GBit
Aktarım Port Sayısı : 1
PoE Port Sayısı :
4 Port
4 Port PoE Güç Bütçesi : 50-130 Watt
