Axis T8508 PoE+ Switch

Name: Axis T8508 PoE+ Switch
Brand: Axis

PoE : PoE Plus

Port Hızı : 1 GBit

Yönetilebilirlik : Yönetilebilir

Aktarım Türü : Combo

Montaj Tipi : Rack Mount

PoE Port Sayısı : Tooltip

8 Port

PoE Güç Bütçesi : 130-200 Watt

Aktarım Port Sayısı : 2

Network Function	DHCP server included
Network Function	VLAN
Security	Password protection, IP address filtering, HTTPS encryption, IEEE 802.1X network access control, ACL, Private VLANs, DHCP Snooping
Supported Protocols	IPv4, IPv6, HTTP, HTTPS, QoS, Bonjour, UPnP, SNMP v1/v2c/v3, DNS, NTP, TCP, UDP, IGMP, ICMP, DHCP, ARP, SSH, STP, RSTP, MSTP, LLDP, LLDP-MED, TFTP, SMTP, BPDU
Throughput	14.9 Mpps
Switching Capacity	20 Gb/s
MAC Address Table	8 K
Jumbo Frames Support	9216 Bytes
Casing	Metal
Casing	Color: Black
Environment	Indoor
Power Requirements	100 to 240 VAC, 50 / 60 Hz
PoE	PoE Class
	Power over Ethernet Plus (PoE+) IEEE 802.3at Type 2 Class 4
	PoE Output
	Port 1 to 8: Up to 30 W
	Power budget: 130 W
Connectors	PoE Ports
	8 x RJ45 10Base-T/100Base-TX/1000Base-T
	Uplink Ports
	2 x Combination port RJ45/SFP 100Base-TX/1000Base-T
	Power Connectors
	1 x Power
	1 x Power connector port
Surge Protection	6 kV on all network ports and AC lines
Temperature & Humidity	Operating Temperature
	32 to 122°F / 0 to 50°C
	Operating Humidity
	10 to 90% non-condensing, RH Storage Temperature
	14 to 158°F / -10 to 70°C
	Storage Humidity
	5 to 95% non-condensing, RH
Management Software	Axis Camera Management
Dimensions	8.6 x 9.52 x 1.73" / 220 x 242 x 44 mm
Weight	4.63 lb / 2.1 kg
Packaging Info
Package Weight	6.0 lb
Box Dimensions (LxWxH)	14.4 x 13.05 x 3.45"
