| Kamera |
| Görüntü Sensörü | 1/3" Super HAD CCD II |
| Video Format | PAL |
| Effective Pixels | 976(H) x582(V), 570K pixels |
| Yatay Çözünürlük | Color: 700TVL, B/W: 750TVL |
| Min.Aydınlatma | Color: 0.001Lux @F1.2, 0.0001Lux @F1.2(Slow shutter, 512x) |
| B/W: 0.0001Lux @F1.2, 0.00001Lux @F1.2(Slow shutter, 512x) |
| Electronic Shutter | Auto: 1/50s~1/100,000s, 10s~1/100,000s@(Slow shutter, 512x) |
| Manual: 1/50s, 1/120s, 1/250s, 1/500s, 1/1000s, 1/2000s, 1/4000s, 1/10,000s |
| Synchronization | Internal / Line lock |
| S/N Oranı | >75dB |
| Video Çıkışı | 1Vp-p Composite Output (75Ω/BNC) |
| Lens |
| Lens Type | Manual / Auto Iris |
| Mount Type | C / CS |
| Operational(OSD) |
| Lens | Manual / DC / Video |
| WDR | Off / On (500x) |
| Shutter / AGC | Auto / Manual |
| Beyaz Denge | ATW / Push / User 1 / User 2 / ANTI CR / Manual / Push lock |
| Backlight | Off / BLC / HLC |
| Picture Adjustment | Mirror / Brightness / Contrast / Sharpness / Hue / Gain |
| ATR-EX | Off / On (Contrast) |
| Hareket Algılama | Off / On (Sensitivity / Block display / Monitoring Area / Area selection) |
| Gizlilik Maskesi | Off / On (Area selection / Mode / Position / Color / Transparent / Mosaic) |
| Day/Night | Auto (ICR) / B/W / Color |
| Gürültü Azaltma | Off / 2D / 3D |
| Digital zoom | Magnitude / Horizontal / Vertical |
| DIS | Off / On |
| Camera ID | Off / On (Character / Position) |
| Dil | English, Chinese |
| Genel |
| İletişim | RS-485 |
| Güç Kaynağı | AC24V±10% / DC12V±10% |
| Güç Tüketimi | Max 6W |
| Çalışma Sıcaklığı | -30°C~+60°C |
| Boyutlar | 131.3mm x 64.6mm x 61.2mm |
| Ağırlık | 500g |
