| Signal System | NTSC |
| Görüntü Sensörü | 1/4" Interline Transfer CCD |
| Lens | 22x Optical Zoom (12x Digital) |
| f/1.6 at 4-88mm |
| Number of Pixels | 380 |
| Yatay Çözünürlük | 470 TV Lines |
| Lux | 2 lux |
| Sinyal Gürültü Oranı | >50 dB |
| Controls | Adjustable to 32 dB |
| Iris Operation | Auto/Manual |
| Pan Angle | 360° |
| Pan Speed | 0.1-360°/s |
| 120°/sec in 22x |
| Tilt Angle | -2.5° above Horizon |
| 92.5° (-2.5° past Vertical). |
| Tilt Speed | 0.1-150°/s |
| 90°/sec in 22x |
| Preset Positions | 79 Programmable Presets |
| Signal Connectors | Video Out: RJ-45 (Ethernet) |
| Relay Output: 3-Position Removable Screw |
| Audio: 1/8" Phono Jack (x2) |
| Sync System | Internal/External (Line Lock on AC Line) |
| Güç Gereksinimi | 18-30 VAC |
| Güç Tüketimi | Coax, Fiber, UTP: 24W |
| ViconNet (TCP/IP): 34W |
| Çalışma Sıcaklığı | 32-132°F (0-55°C) |
| Boyutlar | Diameter: 7.1" (18 cm) |
| Height: 9.7" (24.6 cm) |
| Ağırlık | 5.1 lb (2.3 kg) |
