| Video/Audio Input |
| Audio Input: |
4-ch |
| Video Compression: |
H.264 |
| Analog Video Input: |
32-ch |
| PAL/NTSC Adaptive: |
Support |
| Video Input Interface: |
BNC (1.0 Vp-p, 75Ω) |
| Audio Compression: |
G.711u |
| Audio Input Interface: |
RCA (2.0 Vp-p, 1 kΩ) |
| Two-way Audio: |
1-ch, RCA (2.0 Vp-p, 1 KΩ) (using audio input) |
| Video/Audio Output |
| VGA Output: |
1-ch, resolution: 1920×1080P/60Hz,1280×1024/60Hz,1280×720/60Hz, 1024×768/60Hz |
| CVBS Output: |
1-ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 × 576, NTSC: 704 × 480 |
| HDMI Output: |
1-ch, resolution: 1080P: 1920×1080/60Hz, SXGA: 1280×1024/60Hz, 720P: 1280×720/60Hz, XGA: 1024×768/60Hz |
| Recording resolution: |
WD1/ 4CIF / 2CIF / CIF / QCIF |
| Frame Rate: |
WD1/4CIF/@12 fps(P)/15 fps(N);2CIF/CIF/QCIF @ 25 fps (P)/30 fps (N) |
| Video Bit Rate: |
32Kbps~2048Kbps, or user-defined (Max.3Mbps) |
| Stream Type: |
Video/Video&Audio |
| Audio Output: |
1-ch RCA(Linear, 1kΩ) |
| Audio Bit Rate: |
64kbps |
| Dual Stream: |
Support |
| Playback Resolution: |
WD1/ 4CIF / 2CIF / CIF / QCIF |
| Synchronous Playback: |
16-ch |
| Hard Disk Driver |
| Interface Type: |
2 SATA interfaces |
| Capacity: |
Up to 4TB capacity for each disk |
| External Interface |
| Network Interface: |
1 RJ45 10M/100M adaptive Ethernet Interface |
| USB Interface: |
2 USB 2.0 Interfaces |
| Serial Interface: |
1 RS-485 interface |
| Alarm Input: |
4ch |
| Alarm Output: |
1ch |
| General |
| Power Supply: |
12V DC |
| Consumption: |
≤ 25W |
| Working Temperature: |
-10 ºC ~+55 ºC |
| Working Humidity: |
10%~90% |
| Chassis: |
19-inch rack-mounted 1U chassis |
| Dimensions: |
445 × 290 × 45 mm (W × D × H) |
| Weight: |
≤ 4 kg (without hard disk or DVD-R/W) |
