| Video/Audio Input |
| Audio Input: | 4-ch |
| Video Compression: | H.264 |
| Analog Video Input: | 32-ch |
| PAL/NTSC Adaptive: | Support |
| Video Input Interface: | BNC (1.0 Vp-p, 75Ω) |
| Audio Compression: | G.711u |
| Audio Input Interface: | RCA (2.0 Vp-p, 1 kΩ) |
| Two-way Audio: | 1-ch RCA(2.0Vp-p, 1kΩ) |
| Video/Audio Output |
| VGA Output: | 1-ch, resolution: |
| | 1920×1080P/60Hz,1280×1024/60Hz,1280×720/60Hz, 1024×768/60Hz |
| CVBS Output: | 2-ch (1 Main Video Out+1 Spot Video Out), |
| | BNC (1.0 Vp-p, 75 Ω), |
| | resolution: PAL: 704×576, NTSC: 704×480 |
| Recording resolution: | 4CIF/2CIF/CIF/QCIF |
| Video Spot Output: | 1-ch, BNC(1.0Vp-p, 75Ω) |
| Frame Rate: | 25 fps (P) / 30 fps (N) |
| Video Bit Rate: | 32 Kbps ~ 3072 Kbps, or user defined (Max. 3072 Kbps) |
| Stream Type: | Channel 1-4: Video, Video |
