| System |
| Main Processor |
Embedded Processor |
| Operating System |
Embedded LINUX |
| Display |
| Interface |
2 HDMI (HDMI1 up to 4K), 1 VGA, 1 TV |
| Resolution |
3840×2160, 2560×1440, 1920×1080, 1280×1024, 1280×720, 1024×768 |
| Multi-screen Display |
8CH: 1/4/8/9 |
| 16CH: 1/4/8/9/16 |
| OSD |
Camera title, Time, Video loss, Camera lock, Motion detection, Recording |
| Video Detection and Alarm |
| Trigger Events |
Recording, PTZ, Tour, Alarm Out, Video Push, Email, FTP, Snapshot, Buzzer and Screen Tips |
| Video Detection |
Motion Detection, MD Zones: 396 (22 × 18), Video Loss,Tampering and Diagnosis |
| Alarm input |
8/16 |
| Relay Output |
3 |
| Playback and Backup |
| Playback |
8CH: 1/4/9 |
| 16CH: 1/4/9/16 |
| Search Mode |
Time /Date, Alarm, MD and Exact Search (accurate to second) |
| Playback Function |
Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Repeat, Shuffle, Backup Selection, Digital Zoom |
| Backup Mode |
USB Device/Network |
| Storage |
| Internal HDD |
2 SATA Ports, up to 8TB capacity for each disk |
| eSATA |
1 Port |
| Auxiliary Interface |
| USB |
3 USB Ports (1 USB 2.0 , 2 USB 3.0) |
| RS232 |
1 port, For PC communication & Keyboard |
| RS485 |
1 Port, for PTZ Control |
| Third-party Support |
| Third-party Support |
Dahua, Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec, Vivotek, and more |
| Audio and Video |
| HDCVI Camera Input |
8/16 Channel |
| IP Camera Input |
64 Channel, each channel up to 12MP |
| Audio In/Out |
4/1, BNC |
| Two-way Talk |
1 Mic Input, BNC, 1 Audio Output, RCA |
| Recording |
| Compression |
H.264+/H.264 |
| Resolution |
1080P, 720P, 960H, D1, HD1, BCIF, CIF, QCIF |
| Record Rate |
Main stream: 1080P/720P/960H/D1/HD1/BCIF/CIF/QCIF (1/16-25/30fps) |
| Sub steram:960H/D1/CIF/QCIF(1/16-25/30fps) |
| Bit Rate |
1Kbps - 6144Kbps Per Channel |
| Record Mode |
Manual, Schedule (Regular, Continuous), MD (Video detection: Motion Detection, Video Loss, Tampering), Alarm, Stop |
| Record Interval |
1 - 60 min (default: 60 min), Pre-record: 1 - 30 sec, Post-record: 10 - 300 sec |
| Network |
| Interface |
2 RJ-45 Port (1000M) |
| Network Function |
HTTP, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE,DDNS, FTP, Alarm Server, P2P,IP Search (Support Dahua IP camera, DVR, NVS, etc.) |
| Max. User Access |
128 users |
| Smart Phone |
iPhone, iPad, Android |
| Interoperability |
ONVIF 2.42, CGI Conformant |
| Electrical |
| Power Supply |
DC12V/5A |
| Power Consumption |
<40w without="" hdd="" td=""> |
| Environmental |
| Operating Conditions |
-10°C - +55°C (+14°F - +131°F), 0- 90% RH |
| Storage Conditions |
-20°C - +70°C (-4°F - +158°F) , 0- 90% RH |
| Construction |
| Dimensions |
1U, 375mm×310mm×55mm (14.8" x 12.2" x 2.2") |
| Net Weight |
2.35kg (5.2lb) (without HDD) |
| Gross Weight |
3.2kg (7.05lb) |
| Installation |
Desktop installation |
| Certifications |
| Certifications |
FCC: Part 15 Subpart B ICES 003 Issue 6 |
| CE: EN 55032: 2012+AC:2013 (Class B) |
| EN 55024 : 2010 EN 61000-3-2 : 2014 |
| EN 50130-4: 2011 EN 61000-3-3 : 2013 |
| UL 60950-1 and CAN/CSA C22.2 No. 60950-1-07 |
