| Main Processor | Dual-core embedded processor |
| Operating System | Embedded LINUX |
| Video |
| IP Camera Input | 32 channel |
| Two-way Talk | 1channel Input, 1channel Output, RCA |
| Display |
| Interface | 1 HDMI,1 VGA |
| Resolution | 1920×1080, 1280×1024, 1280×720, 1024×768 |
| Display Split | 1/4/8/9/16/36 |
| OSD | Camera title, Time, Video loss, Camera lock, Motion detection, Recording |
| Recording |
| Compression | H.264/MJPEG |
| Resolution | 5Mp（2560×1920）/3Mp（2048×1536）/1080P(1920×1080) / 720P(1280×720) / D1 (704×576/704×480)&etc. |
| Record Rate | 100Mbps |
| Bit Rate | 48~ 8192kbps |
| Record Mode | Manual, Schedule(Regular(Continuous), MD, Alarm), Stop |
| Record Interval | 1~120 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec |
| Video Detection & Alarm |
| Trigger Events | Recording, PTZ, Tour, Alarm, Video Push, Email,FTP, Buzzer & Screen tips |
| Video Detection | Motion Detection,MD Zones: 396(22×18), Video Loss & Camera Blank |
| Alarm Input | N/A |
| Relay Output | N/A |
| Playback & Backup |
| Sync Playback | 1/4/9/ |
| Search Mode | Time/Date, Alarm, MD & Exact search (accurate to second), Smart search |
| Playback Function | Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection, Digital zoom |
| Backup Mode | USB Device/Network/Internal SATA burner |
| Network |
| Ethernet | 1 RJ-45 port (10/100) |
| PoE | N/A |
| Network Function | HTTP, TCP/IP, IPv4/IPv6, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPOE, DDNS, FTP, Alarm Server, IP Search(Support Dahua IP camera, DVR, NVS and etc.) |
| Max. User Access | 29users |
| Smart Phone | iPhone, iPad, Android, Windows Phone |
| Storage |
| Internal HDD | 8 SATA ports, up to 32TB |
| Auxiliary Interface |
| USB | 2 ports (USB 02 |
| RS232 | N/A |
| RS485 | N/A |
| General |
| Power Supply | 220W 350 POWER SUPPLY |
| N/A |
| Power Consumption | N/A |
| N/A |
| Working Environment | -10°C ~+55°C / 10%~90%RH / 86~106kpa |
| Dimension | 1U, 425mm×319mm×85mm |
| (W×D×H) |
| Weight | 2.0KG(without HDD) |
