| Video/Audio Input |
  | Two-way audio input | 1-ch, RCA (2.0 Vp-p, 1kΩ) |
  | IP video input | 32-ch |
  | Network |
  | Remote connection | 128 |
  | Incoming bandwidth | 256Mbps |
  | Outgoing bandwidth | 200Mbps |
  | Video/Audio Output |
  | HDMI/VGA output | 3-ch, HDMI1 4K (3840 × 2160)/60Hz, 4K (3840 × 2160)/30Hz, 2K(2560×1440)/60Hz,1920 × 1080p/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz,1280 × 720/60Hz, 1024 × 768/60Hz; HDMI2 1920×1080/60Hz, 1280×1024/60Hz, 1280×720/60Hz,1024×768/60Hz; VGA 2K(2560×1440)/60Hz,1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280× 720/60Hz, 1024 × 768/60Hz,HDMI1/VGA Simultaneous Output |
  | Recording Resolution | 12MP/8MP/6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
  | Audio Output | 1-ch, RCA (Linear, 1kΩ) |
  | Synchronous Playback | 16-ch |
  | Decoding |
  | Capability | 16-ch @ 1080p |
  | Live view / Playback | 12MP/8MP/6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
  | Hard Disk |
  | SATA | 4 SATA interfaces for 4HDDs |
  | Capacity | Up to 8TB capacity for each HDD |
  | External Interface |
  | Network Interface | 2 RJ-45 10/100/1000Mbps self-adaptive Ethernet interfaces |
  | Serial Interface | RS-232, RS-485, Keyboard |
  | USB Interface | Front panel 2 × USB 2.0 |
  | Rear panel 1 × USB 3.0 |
  | Alarm In | 16-ch |
  | Alarm Out | 8-ch |
  | POE |
  | Supported Standard | AF and AT |
  | Interface | 24 independent 10/100 Mbps PoE Ethernet interfaces |
  | Max. Power | 200W |
  | General |
  | Power Supply | 100 to 240 VAC |
  | Power | ≤350 W |
  | Consumption(without hard disk and POE) | ≤30 W |
  | Working Temperature | -10 oC ~ +55 oC (+14 oF~ + 131 oF) |
  | Working Humidity | 10 % ~ 90 % |
  | Chassis | 19-inch rack-mounted 1.5U chassis |
  | Dimensions | 445 × 400 ×71 mm ( 17.5"× 15.7" × 2.8") |
  | Weight(without HDD) | ≤ 5 Kg (11 lb) |
