| Video/Audio Input |
| Two-way audio input | 1-ch, RCA (2.0 Vp-p, 1kΩ) |
| IP video input | 4-ch |
| Network |
| Incoming bandwidth | 40Mbps |
| Outgoing bandwidth | 40Mbps |
| Video/Audio Output |
| HDMI/VGA output | 1-ch, resolution: |
| 1920 × 1080P /60Hz, 1600 × 1200 /60Hz, 1280 × 1024 /60Hz, 1280 × 720 /60Hz, |
| 1024 × 768 /60Hz |
| Frame Rate | Main stream: 50 fps (P) / 60 fps (N) |
| Sub-stream: 50 fps (P) / 60 fps (N) |
| Audio Output | 1-ch, RCA (Linear, 1kΩ) |
| Decoding |
| Capability | 4-ch@1080P |
| Hard Disk |
| SATA | 1 SATA interface for 1 HDD |
| Capacity | Up to 6TB capacity for each HDD |
| External Interface |
| Built-in switch network interface | 4 independent 100 Mbps built-in |
| switch network interfaces |
| Network Interface | 1 RJ-45 10 / 100 Mbps selfadaptive |
| Ethernet interface |
| USB Interface | 2, USB2.0 |
| POE |
| Supported Standard | AF and AT |
| Interface | 4 independent 100 Mbps PoE |
| network interfaces |
| Max. Power | 50W |
| General |
| Power Supply | 48 VDC |
| Consumption(without hard disk and POE) | ≤ 60 W |
| Working Temperature | -10 oC ~ +55 oC (+14 oF~ + 131 oF) |
| Working Humidity | 10 % ~ 90 % |
| Chassis | Stand-alone 1U chassis |
| Dimensions | 200 × 205 × 48 mm |
| (7.9" × 8.1" × 1.9") |
| Weight(without HDD) | ≤ 1 kg (2.2 lb) |
