Açıklama

Cisco IE 4000 4S8P4G E Endüstriyel PoE Switch

Physical Specification
Total Ports	16
GE combo uplinks (4G)	4 GE combo uplink ports
	(Combo ports provide one copper and one fiber physical port and only one can be activated at a time.)
SFP fiber ports (S)	4 FE
PoE PoE ports (P, GP), Maximum PoE power budget	8 (FE), 125W
Default software	LAN Base feature set (Can be upgraded to IP Services at a fee.)
Hardware	- 1GB DRAM
	- 128-MB onboard flash memory
	- 1-GB removable SD flash memory card
	- Mini-USB connector
	- RJ-45 connector
Alarm	Alarm I/O: two alarm inputs to detect dry contact open or closed, one alarm output relay
Power Input	- Redundant DC input voltage with operating range: nominal 9.6 to 60VDC
	- Maximum DC input current: 4.3A
Power consumption	40W
Dimensions (H x W x D)	6.12 x 6.12 x 5.09 in. (155.4 x 155.4 x 129.2 mm)
Weight	6.35 pounds (2.88 kg)
Switch performance and scalability
Forwarding rate	Line rate for all ports and all packet sizes
Number of queues	4 egress
Unicast MAC addresses	16
IGMP multicast groups	1
Number of VLANs	1
IPv4 MAC security ACEs	1,000 with default TCAM Template
NAT translation	Bidirectional, 128 unique subnet NAT translation entries, which can expand to tens of thousands of translated entries if designed properly
