Açıklama
TP-Link TL SL1218MP PoE Switch
Özellikler
- 16 PoE+ 10/100Mbps RJ45 ports, 2 Gigabit RJ45 ports and 2 combo Gigabit SFP slots
- Up to 250m data and power transmission under extend mode specially designed for surveillance system
- Priority mode for port1-8 to guarantees the quality of sensitive applications like video monitor
- High PoE power budget with up to 30W for each PoE port and 194W for all PoE ports
- Easy to use, with no configuration and installation needed
Teknik Özellikler
| HARDWARE FEATURES | |
| Interface | 16 PoE+ 10/100Mbps RJ45 Ports |
| 2 10/100/1000Mbps RJ45 Ports | |
| 2 Combo Gigabit SFP Slots | |
| Network Media | 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m) |
| EIA/TIA-568 100Ω STP (maximum 100m) | |
| 100BASE-TX: UTP category 5, 5e cable (maximum 100m) | |
| EIA/TIA-568 100Ω STP (maximum 100m) | |
| 1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m) | |
| EIA/TIA-568 100Ω STP (maximum 100m) | |
| 1000BASE-X MMF, SMF | |
| Fan Quantity | 2 Fans |
| Power Supply | 100-240V AC, 50/60 Hz |
| Backup Bandwidth | 7.2 Gbps |
| PoE+ Ports(RJ45) | Standard: 802.3at/802.3af compliant |
| PoE Ports: Port1- Port16 | |
| PoE Power Budget: 192W | |
| Mac Address Table | 8K |
| Dimensions ( W x D x H ) | 17.3 × 7.1 × 1.7 in. |
| (440 × 180 × 44 mm) | |
| Max Power Consumption | 18.7 W (no PD connected) |
| 217.2 W (with 192W PD connected) | |
| Max Heat Dissipation | 63.9 BTU/h (no PD connected) |
| 741.2 BTU/h (with 192W PD connected) | |
| SOFTWARE FEATURES | |
| Advanced Features | Compatible with IEEE 802.3at/af compliant devices |
| Port Priority Mode | |
| Extend Mode (Up to 250m PoE power supply and data transmission) | |
| Mac Address Auto-Learning And Auto-Aging | |
| IEEE802.3x Flow Control | |
| Transmission Method | Store-And-Forward |
| OTHERS | |
| Certification | FCC, RoHS |
| Package Contents | TL-SL1218MP |
| Power Cable | |
| Installation Guide | |
| Environment | Operating Temperature: 0°C~40°C (32°F~104°F) |
| Storage Temperature: -40°C~70°C (-40°F~158°F) | |
| Operating Humidity: 10% ~ 90% non-condensing | |
| Storage Humidity: 5%~90% non-condensing | |
Teknik Kısa
PoE : PoE
Port Hızı : 100 Mbps
Yönetilebilirlik : Yönetilemez
Aktarım Port Sayısı : 2
Aktarım Türü : Gbit Fiber
Montaj Tipi : Rack Mount
PoE Port Sayısı :
16 Port
16 Port PoE Güç Bütçesi : 130-200 Watt
