Açıklama
ZyXEL ES3500 24HP 24 Port 10/100 4XDual SFP L2 Yönetilebilir PoE Switch
Özellikler
- Tipi: Sabit Portlu
- Modül Desteği: Yok
- Yönetilme Durumu: Yönetilebilir (TAM)
- Türü: Layer 2
- Port sayısı: 24
- Yoğunluklu Port tipi: 10/100Mbps
- Ek özellikler: IPv6 Desteği, PoE
- Uplink Port Tipi: 10/100/1000 Bakır, 1000Mbps Fiber
- Maximum PoE power budget 180W
- 24x10/100 Base T PoE + 4 Dual Personality GbE Port
- QoS çoklu hizmet kalitesini optimum seviyede kullanma
- GMP inceleme v1, v2, v3, MVR
- Güvenlik koruması için çok katmanlı (L2/L3/L4) ACL seti
- RSTP, & Port trunking ile yüksek yedekleme özelliği ve esnek mimari
- IPv6 yönetim desteği
- IEEE 802.3at PoE Plus standardı
- PoE tüketim modu ile gelişmiş enerji verimliliği
- Port Sayısı : 10/100BASE-TX 24 Port, Dual-personality 4 Port
- Performans : Switching kapasite 12.8 Gbps, Forwarding rate 9.6 Mpps, Packet buffer 320K, MAC address 16K
- Güç: Input 100 - 240 V AC, 50/60 Hz, Max. power consumption 14W
Teknik Özellikler
| Performance |
| Density |
| Port: 10/100BASE-TX PoE |
| 24 |
| Dual-Personality GbE |
| 4 |
| Switching Capacity |
| 12.8 Gb/s |
| Forwarding Rate |
| 9.6Mb/s |
| Packet Buffer |
| 320 KB |
| MAC Address |
| 16 K |
| Standard Compliance : |
| IEEE 802.3 10BASE-T Ethernet |
| IEEE 802.3u 100BASE-Tx Ethernet |
| IEEE 802.ab 1000BASE-T Ethernet |
| IEEE 802.3z 1000BASE-X |
| IEEE 802.3x flow control |
| IEEE 802.1d spanning tree protocol |
| IEEE 802.1w rapid spanning tree protocol |
| IEEE 802.1s multiple spanning tree protocol |
| IEEE 802.1p class of service, priority protocols |
| IEEE 802.1Q VLAN tagging |
| IEEE 802.1X port authentication |
| IEEE 802.3ad LACP aggregation |
| IEEE 802.3az Energy Efficient Ethernet (EEE) |
| IEEE 802.3at |
| IEEE 802.3af |
| Power |
| Power Input |
| 100 to 240 V AC, 50/60 Hz |
| Power Consumption |
| Maximum: 236 W |
| Total PoE Budget |
| 180 W |
| Environmental |
| Heat Dissipation |
| 804.8 BTU/hr |
| Temperature |
| Operating |
| 32 to 122°F (0 to 50°C) |
| Storage |
| -40 to 158°F (-40 to 70°C) |
| Humidity |
| Operating: 10 to 95% (non-condensing) |
| Management |
| Traffic Management and QoS |
| Broadcast storm control |
| IEEE 802.1p with 8 hardware priority queues per port for different types of traffic |
| IEEE 802.1Q tag-based and port-based VLAN |
| Weighted Fair Queuing (WFQ)/WRR/SPQ scheduling algorithm |
| Policy based rate limiting |
| Policy based bandwidth control |
| Port based traffic shaping |
| Policy-based traffic mirroring |
| IGMP snooping (v1, v2, v3) |
| IGMP filtering |
| Jumbo frame support (9KB) for high performance data backup or recovery services |
| Support GVRP, automatic VLAN member registration |
| Multicast VLAN Registration (MVR) |
| Q in Q |
| Selected Q in Q |
| Link Aggregation |
| IEEE 802.3ad LACP link aggregation compliant |
| Support static manually port trunking |
| Up to 8 aggregation groups, 8 ports/per group randomly selected |
| VLAN trunking |
| Network Resilience |
| IEEE 802.1w Rapid Spanning Tree Protocol (RSTP) provides rapid convergence of spanning tree independent of spanning-tree timer |
| IEEE 802.1s multiple spanning tree provides link availability in multiple VLAN environments by allowing multiple spanning trees |
| MRSTP- Multiple RSTP |
| User Security and Authentication |
| IEEE 802.1X authentication |
| IP source guard (static IP/MAC binding, DHCP snooping, ARP inspection) |
| IP subnet VLAN & VLAN isolation |
| Limiting MAC number per port |
| Loop guard prevents a switch from being affected by another switch which is already in a looping status |
| MAC filtering per port secures access to each port |
| MAC freeze |
| Port security, port isolation, port mirroring |
| Static MAC forwarding per port; only specified MAC addresses can access the network (port security) |
| Wire speed filtering per MAC/IP/TCP/UDP |
| Wire speed mirroring per MAC/IP/TCP/UDP |
| Wire speed rate limiting per MAC/IP/TCP/UDP |
| GVRP, automatic VLAN member registration |
| Guest VLAN |
| CPU protection |
| PPPoE option 82 |
| Network Administration Security |
| SSH v1/v2 |
| SSL |
| RADIUS accounting |
| TACACS+ authentication, accounting |
| NTP, daylight saving |
| IPv6 Host : |
| IPv6 over Ethernet (RFC 2464) |
| IPv6 Addressing Architecture (RFC 4291) |
| Dual stack (RFC4213) |
| ICMPv6 (RFC4884) |
| Path MTU (RFC 1981) |
| Minimum Path MTU size of 1280 (RFC 5905) |
| Encapsulation for minimum PMTU of 1500 |
| Neighbor Discovery (RFC4861) |
| DHCPv6 Relay/Client |
| Network Management |
| Supports ZyXEL iStacking, up to 24 switches can be managed by one IP address |
| Intuitive web-based management with all features configurable |
| Text-based configuration profile for massive deployment |
| Telnet CLI (Cisco like) |
| SNMP v1, v2c, v3 |
| SNMP trap group |
| RMON four RMON groups 1, 2, 3, 9 (history, statistics, alarms, and events) for enhanced traffic management, monitoring, and analysis |
| Out-of-Band Management: RS-232c local console |
| Firmware upgrade, configuration backup/restore via ftp |
| Alarm led indicator for early warning of hardware troubles |
| Send system trap to trap server |
| DHCP relay, DHCP relay per VLAN, DHCP relay option 82, DHCP client |
| Port Mirroring: supports source/destination/ both port mirroring |
| IEEE 802.3ah Ethernet operations, Administration and Management (OAM) |
| sflow |
| Intelligent ACL |
| L2/L3/L4 Access List Control |
| Based on port |
| Based on MAC + VLAN ID |
| Based on IP address (source/destination) |
| Based on protocol type |
| Based on TCP/UDP port number |
| MIB Information |
| RFC1213 MIB II |
| RFC1493 Bridge MIB |
| RFC1643 Ethernet MIB |
| RFC1757 RMON group 1, 2, 3, 9 |
| RFC2011 IP MIB |
| RFC2012 TCP MIB |
| RFC2013 UDP MIB |
| RFC2233 ifVHC Packet Group |
| RFC2674 VLAN MIB |
| RFC2925 PING-MIB and TRACEROUTE-MIB |
| ZyXEL private MIB |
| Management Information Base (MIB) for IP (RFC4293) |
| IP Forwarding Table MIB (RFC4292) |
| Management Information Base for Transmission Control Protocol (RFC4022) |
| Management Information Base for User Datagram Protocol (RFC4113) |
| Safety Agency Approvals |
| EN 55022: 2006+A1: 2007 |
| EN 61000-3-2 |
| EN 61000-3-3 |
| EN 55024 |
| AS/NZS CISPR 22: 2009 |
| FCC Part 15 (Class A, Class B) |
| ICES-003 |
| BSMI (CNS13438, CNS14336) |
| EN 60950-1 |
| General |
| MTBF |
| 773887.2 hours |
| Compliance |
| FCC, CE, RoHS |
| Dimensions (W x H x D) |
| 17.3 x 1.7 x 12.9" (440.0 x 44.5 x 330.0 mm) |
| Weight |
| 9.4 lb (4.3 kg) |
ZyXEL ES3500 24HP 24 Port 10/100 4XDual SFP L2 Yönetilebilir PoE Switch PDF Dosyası1.17 MB
Teknik Kısa
PoE : PoE Plus
Port Hızı : 100 Mbps
Yönetilebilirlik : Yönetilebilir Layer 2
Aktarım Port Sayısı : 4
Aktarım Türü : Gbit Fiber
PoE Port Sayısı :
24 Port
24 Port PoE Güç Bütçesi : 130-200 Watt
