TP-Link TL SG1005P PoE Switch
Özellikler
- 5 10/100/1000Mbps RJ45 ports
- With four PoE ports, transfers data and power on one single cable
- Working with IEEE 802.3af compliant PDs, expands home and office network
- 802.1p/DSCP QoS enable smooth latency-sensitive traffic
- Supports PoE Power up to 15.4W for each PoE port
- Supports PoE Power up to 56W for all PoE ports
- Requires no configuration and installation
Teknik Özellikler
| DONANIM ÖZELLİKLERİ | |
| Arabirim | 5 10/100/1000Mbps RJ45 Ports |
| AUTO Negotiation/AUTO MDI/MDIX | |
| Ağ Medyası | 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m) |
| EIA/TIA-568 100Ω STP (maximum 100m) | |
| 100BASE-TX: UTP category 5, 5e cable (maximum 100m) | |
| EIA/TIA-568 100Ω STP (maximum 100m) | |
| 1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m) | |
| EIA/TIA-568 100Ω STP (maximum 100m) | |
| Fan Sayısı | Fanless |
| Güç Tüketimi | 63.31W (max. with 56w PoE device connected) |
| 4.26W (max. no PoE device connected) | |
| Harici Güç Kaynağı | External Power Adapter(Output: 48VDC / 1.25A) |
| PoE Portları (RJ45) | Standard: 802.3 af compliant |
| PoE Ports: Port1- Port4 | |
| Power Supply: 56W | |
| Backbound Bandwidth | 10Gbps |
| MAC Adres Tablosu | 2K |
| Boyutlar ( W X D X H ) | 3.9 x 3.9 x 1.0 in. (99.8 x 98 x 25 mm) |
| Maks. Güç Tüketimi | 3.95W(220/50Hz. no PD connected) |
| 64.44W(220/50Hz. with 56W PD connected) | |
| Max Heat Dissipation | 13.48BTU/h(no PD connected) |
| 219.87BTU/h(with 56W PD connected) | |
| YAZILIM ÖZELLİKLERİ | |
| Gelişmiş Özellikler | Compatible With IEEE 802.3af Compliant PDs |
| Priority Function | |
| Mac Address Auto-Learning And Auto-Aging | |
| EEE802.3x Flow Control | |
| 802.1p/DSCP QoS | |
| IGMP Snooping | |
| Transfer Metodu | Store-And-Forward |
| DİĞERLERİ | |
| Sertifika | FCC, CE, RoHS |
| Paket İçeriği | TL-SG1005P, Power Adapter, Installation Guide |
| Tüketim | 4.26 watts (max. no PD connected) |
| 63.31 watts (max. with 56w PD connected) | |
| Ortam | Operating Temperature: 0℃~40℃ (32℉~104℉) |
| Storage Temperature: -40℃~70℃ (-40℉~158℉) | |
| Operating Humidity: 10%~90%RH non-condensing | |
| Storage Humidity: 5%~90%RH non-condensing | |
Teknik Kısa
PoE : PoE
Port Hızı : 1 GBit
Yönetilebilirlik : Yönetilemez
Aktarım Port Sayısı : 1
Aktarım Türü : Rj45
Montaj Tipi : Desk Mount
PoE Port Sayısı :
4 Port
4 Port PoE Güç Bütçesi : 50-130 Watt
