HP 2530 8 PoE Plus J9780A 10/100 PoE Switch
Teknik Özellikler
| Differentiator |
| The HP 2530-8-PoE+ Switch is a fully managed layer 2 switch with 8 10/100 PoE+ ports and 2 dual personality ports. |
| Ports |
| (8) RJ-45 autosensing 10/100 PoE+ ports |
| (2) dual-personality ports - each port can be used as either an RJ-45 10/100/1000 port (IEEE 802.3 Type 10Base-T |
| IEEE 802.3u Type 100Base-Tx |
| IEEE 802.3ab 1000Base-T Gigabit Ethernet) or as a SFP slot (for use with SFP transceivers) ports |
| Memory and processor |
| ARM9E @ 800 MHz |
| 128 MB flash |
| Packet buffer size: 1.5 MB dynamically allocated |
| 256 MB DDR3 DIMM |
| Latency |
| 100 Mb Latency: < 1.3 µs |
| 1000 Mb Latency: < 1.3 µs |
| Throughput |
| up to 4.1 Mpps |
| Switching capacity |
| 5.6 Gbps |
| PoE capability |
| 67 W |
| Stacking capabilities |
| Virtual |
| 16 switches |
| Management features |
| IMC - Intelligent Management Center |
| Command-line interface |
| Web browser |
| Configuration menu |
| Out-of-band management (serial RS-232c or micro usb) |
| IEEE 802.3 Ethernet mib |
| Repeater mib |
| Ethernet interface mib |
| Dimensions and weight |
| Dimensions (W x D x H) |
| (25.4 x 15.95 x 4.45 cm) |
| Weight |
| (0.91 kg) |
Teknik Kısa
PoE : PoE Plus
Port Hızı : 100 Mbps
Yönetilebilirlik : Yönetilebilir Layer 2
Aktarım Port Sayısı : 2
Aktarım Türü : Gbit Fiber
PoE Port Sayısı :
8 Port
8 Port PoE Güç Bütçesi : 50-130 Watt
Montaj Tipi : Rack Mount
