| Networking Protocol |
| IPV4, ARP, TCP, UDP, ICMP |
| DHCP Client |
| NTP Client (D-Link) |
| DNS Client |
| DDNS Client (Dyndns and D-Link) |
| SMTP Client |
| FTP Client |
| HTTP Server |
| PPPoE |
| UPnP Port Forwarding |
| LLTD |
| Built-In Protocol |
| 10/100 BASE-TX Fast Ethernet |
| 802.11b/g/n WLAN |
| Wireless Connectivity |
| 802.11b/g/n Wireless with WEP/WPA/WPA2security |
| WPS |
| Wireless Transmit Output Power (Typical) |
| 11b - 16 dbm |
| 11g/11n - 12 dbm |
| SDRAM |
| 64 MB |
| Flash Memory |
| 8 MB |
| Reset Button |
| Reset to factory default |
| Video Codecs |
| H.264 |
| MJPEG |
| JPEG for still images |
| Video Features |
| Adjustable image size and quality |
| Time stamp and text overlay |
| Flip and Mirror |
| Resolution |
| 640 x 480 at up to 30 fps |
| 320 x 240 at up to 30 fps |
| 160 x 112 at up to 30 fps |
| Lens |
| Focal length: 2.2 mm, F2.0 |
| IR LED |
| 8 meter illumination distance with 10 LEDs and light sensor |
| Viewing Angle |
| Horizontal: 66.2° |
| Vertical: 49.08° |
| Diagonal: 77.04° |
| Pan/Tilt Range |
| Pan Range: +170° ~ -170° (Total 340°) |
| Tilt Range: +95° ~ -25° (Total 120°) |
| Digital Zoom |
| Up to 4x |
| 3A Control |
| AGC (Auto Gain Control) |
| AWB (Auto White Balance) |
| AES (Auto Electronic Shutter) |
| Power |
| Input: 100-240 V AC, 50/60 Hz |
| Output: 12 V DC, 1 A |
| Dimensions |
| Camera Only - 102.35 x 101.27 x 133.6 mm(4.03 x 3.99 x 5.26 inches) |
| Camera Including Mounting Bracket -102.35 x 101.27 x 230.0 mm(4.03 x 3.99 x 9.06 inches) |
| Max Power Consumption |
| 8.64W |
| Operation Temperature |
| 0 ˚C to 40 ˚C (32 ˚F to 104 ˚F) |
| Storage Temperature |
| -20 ˚C to 70 ˚C (-4 ˚F to 158 ˚F) |
| Certifications |
| FCC Class B |
| CE |
| CE LV D |
| C-Tick |
