| SKU | DS-2TD2617-3/V1 |
| Manufacturer | Hikvision |
| Features | Audio, Auto Gain Control, Day/Night, Digital Noise Reduction, On Screen Display Menu, Weather Resistant, Wide Dynamic Range |
| Camera Signal | Network IP |
| Connection Type | Wired |
| Infrared Distance | 101 Feet + |
| Resolution | 160 X 120 |
| Lens Type | Fixed |
| Lens Size | 4 mm, 3.1mm |
| Mount Type | Ceiling, Wall |
| Compression Method | H.264, M-JPEG, H.265, H.264+, H.265+ |
| Durability | Weather Resistant |
| Voltage | 12vDC, PoE |
| Dimensions (W x H) | 13.9" x 4.5" x 4.5" (352.4 mm x 113.5 mm x 114.7 mm) |
| Electronic Shutter | 1s to 1/100,000s |
| Image Device | 1/2.8" Progressive Scan CMOS |
| Minimum Scene Illumination | Color: 0.002 lux @ (ƒ/1.5, AGC on), B/W: 0.0002 lux @ (ƒ/1.5, AGC on) |
| Operating Humidity | 90% or less |
| Operating Temperature | -40° to 140° F (-40° to 60° C) |
| OSD Menu | English |
| Power Consumption | 12 VDC ± 20%: maximum 12 W, PoE (802.3af, class 4) |
| Protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour |
| Weatherproof | IP66 |
| Digital Noise Reduction | 3D DNR |
| Angle of View | 3.1 mm: 50° x 37.2, 4 mm: 87° x 46.2° |
| IR Distance | 40m/130ft |
| Audio | Yes |
| Auto Gain Control | Yes |
| Day/Night | Yes |
| Digital Noise Reduction | Yes |
| On Screen Display Menu | Yes |
| Wide Dynamic Range | Yes |
