| Imaging Device |
1/4'' CMOS |
| Total Pixels |
1280H x 800V |
| Scanning System |
Progressive Scan |
| Synchronization |
Internal |
| Video Output P/N |
AHD : 1.0MP 720P |
| CVBS:1200 Tvl |
| Lens |
3.6 mm / |
| IR Led |
6 Array Led |
| S/N Signal |
＞46db |
| Min. IIIumination |
（Color）：0.05LUX （F1.2，501RE） |
| （B/W）：0.03LUX （F1.2，501E） |
| ESC |
1/50（60）~1/100，000（120，000）sec |
| Day/Night Selection |
Color/Auto D/N /B/W/EXT |
| Gain Control |
0db-42db |
| Whtie Balance |
ATW2700°K~10500°K |
| AWC-SET/INDOOR/OUTDOOR/MANUAL /AWB |
| Motion Detenction |
On/Off Programmable 4 Zones |
| Privacy Making |
On/Off Programmable 4 Zones |
| DNR |
2DNR/3DNR |
| Digital Effect |
（FREEZE） |
| U/D/L/R,MIRROR |
| Input Voltage |
DC 12V |
| Power Consumption |
Max 5w |
| Operating Temp/Hum |
-10℃ ~ 80℃ / 30%RH ~ 90%RH |
| Storage Temp/Hum |
-10℃ ~ 80℃ / 30%RH ~ 90%RH |
