| Camera |
| Image Sensor |
1/2.9” Progressive Scan CMOS |
| Effective Pixels |
1920(H) x 1080(V) |
| Scanning System |
Progressive |
| Electronic Shutter |
Auto, PAL:1/50-1/50000s, NTSC:1/60-1/60000s |
| Min. illumination |
Color:0.01Lux@(F1.2,AGC ON) ; |
| B/W:0Lux@(IR LED ON) |
| S/N Ratio |
More than 48dB |
| IR Range |
up to 15m |
| IR On/Off Control |
Auto/Manual |
| IR LEDs |
12pcs |
| OSD Joystick |
N/A |
| Up the Coax |
Support |
| Pan/Tilt/Rotation Range |
Pan:0˚~360˚; Tilt:0˚~90˚; Rotation:0˚~360˚ |
| Lens |
| Lens Type |
Fixed |
| Iris |
Fixed Iris |
| Focal Length |
3.6mm |
| F Number |
F2.0 |
| Angle of View |
85° |
| Focus Control |
Fixed |
| Close Focus Distance |
0.5m |
| Video |
| Resolution |
1080P (1920×1080) |
| Frame Rate |
PAL:25fps ,NTSC:30fps |
| Video Output |
Support AHD/TVI/CVI/CVBS Output |
| Day/Night |
Ext /AUTO /Color/MONO |
| OSD Menu |
Support |
| Wide Dynamic Range |
dWDR, OFF/ON |
| Gain Control |
Auto |
| Noise Reduction |
3DNR, AUTO/MANUAL(1-10) |
| White Balance |
Auto |
| BLC |
Support |
| Mirror |
N/A |
| Motion Detection |
Support |
| Privacy Masking |
Support |
| General |
| Power Supply |
DC12V±10% |
| Power Consumption |
Max. 3W (12V DC, IR ON) |
| Operating Temperature |
-10 °C ~ 55 °C (14°F ~ 131 °F) |
| Operating Humidity |
Less than 85% RH |
| Ingress Protection |
N/A |
| Certifications |
CE/FCC |
| Casing |
Plastic |
| Dimensions |
Φ69.6×148.6mm |
| Net Weight |
130g |
