| CAMERA |
| Image Sensor | 1/2.9” Sony CMOS |
| Signal System | PAL/NTSC |
| Min. illumination | Color:0.01Lux@(F1.2,AGC ON) ; |
| B/W:0Lux@(IR LED ON) |
| S/N Ratio | ≥50dB |
| Day & Night | ICR |
| Shutter Speed | PAL:1/50-1/50000 NTSC:1/60-1/60000 |
| Wide Dynamic Range | dWDR |
| Digital Noise Reduction | 2D |
| Lens | 3.6mm |
| FOV | 85° |
| IR LED | 24pcs |
| IR Wavelength | 850nm |
| IR Range | Up to 20m |
| OSD Joystick | Support |
| Up the Coax | Support |
| IMAGE |
| Effective Resolution | 1920x1080 |
| Frame | PAL:25fps ,NTSC:30fps |
| Mirror | N/A |
| Defog | N/A |
| HLC | N/A |
| Privacy Masking | N/A |
| Motion Detection | N/A |
| VIDEO OUTPUT | |
| Max Distance | 75-5 300m |
| Video Output | AHD/TVI/CVI/CVBS |
| GENERAL |
| Power Supply | DC12V±10% |
| Power Consumption | 3.5W(Max) |
| Operating Temperature | -10°C ~ 55°C (14°F ~ 131°F ) |
| Operating Humidity | 0% - 85% RH |
| Ingress Protection | IP66 |
| Approvals | CE / FCC |
| Material | Aluminium Alloy |
| Product Dimensions | 194.35mm x 63 x 63mm |
| Product Weight | 490g |
