Özellikler
- High performance NVR with Full HD realtime recording capability
- Easy to use user interface
- Auto configuration for Grundig IP cameras
- Built in PoE Switch for direct IP camera connection
- Control the NVR directly by mouse (USB) or by remote over IP
Teknik Özellikler
- Operating System: Embedded Linux
- IP Inputs: 4 channels
- Video Outputs: 1x HDMI
- Max. Storage Capacity: 28 TB (2x4 TB SATA and 5x4 TB eSATA)
- Harddisk bay: 2 x SATA II
- Video Compression: H.264
- Recording Resolution: max. 1920x1080 depending on the camera performance
- Recording Speed: 100 fps
- Recording Mode: Continuous, Event Alarm, Motion, Video Loss, Schedule, Manual
- Pre-Alarm: Off, 1, 2, 3, 4, 5, 10, 15 sec.
- Post-Alarm: Off, 1, 2, 3, 4, 5, 10, 15, 30, sec., 1, 2, 3 min.
- Display Resolution: 1920 x 1080
- Display Speed: 100 fps
- Display Mode: Full screen, 4
- PTZ Control: Pan / Tilt / Zoom / Focus / Preset / Sequence / Auto Pan
- Auto Switching: 1, 2, 3, 5, 10, 15, 20, 30, 40, 60 sec, Multi Channel Views
- External Backup: USB HDD, USB Memory,Network, FTP
- Watermark: Yes
- Search Mode: Date/Time, Event, Thumbnail
- Motion Detection: On/ Off/ Sensitivity/ Area setting
- Event Source: Motion, Alarm, Video Loss, System
- Event Action: Pop-Up, Relay, E-Mail, Buzzer
- Number of Clients: Up to 8 user (admin, manager, user)
- Audio Inputs: 4 CH over IP, 1x RCA
- Audio Outputs: 1 CH, RCA
- Audio Compression: G.711
- Alarm Inputs: 4 (IP) + 2 N/O or N/C
- Alarm Outputs: 1 Relay
- Network Interface: 4x 10/100 Base T/TX PoE (RJ-45) + 2x 10/100/1000 Base T/TX (RJ-45)
- PoE Budget: 60 W
- Serial Interface(s): 1x RS232, 1x RS485, 3x USB, 1x eSATA
- Multiplex Function: Triplex
- Network Protocol: DHCP; HTTP; FTP; SMTP; RTP/RSTP; RTCP; NTP; DDNS; uPNP
- Video Streaming: Versatile Dual Streaming
- Time Setting: Setting by NTP Server local or internet
- Client software: Windows (XP, Vista, 7), Web Viewer: IE, Firefox, Safari, Chrome; Mobile: iPhone, Android
- Operating Temperature: 0°C ~ +40°C
- Humidity: less than 90%, non condensing
- Supply Voltage: 12 VDC (NVR), 48 VDC (PoE Switch)
- Certification: FCC,CE
- Power Consumption: 20 W
- Weight: 4.09 kg
- Dimensions w*h*d: 305 x 44 x 298 mm
Grundig GRI K1104A NVR Kayıt Cihazı PDF Dosyası199.62 KB
