Açıklama
Micronet SP6310IC2 Endüstriyel PoE Switch
Özellikler
- 8 Port 802.3af PoE desteği
- 2 Combo Bakır Port, 2 SFP port
- Port başına 15.4 Watt toplamda 130 Watt
- Yönetilebilir Layer2+
- Endüstriyel yapıda(-400 - +750 )
Teknik Özellikler
| Arayüz | IEEE 802.3 10Base-T Ethernet IEEE 802.3u 100Base-TX IEEE 802.3ab 1000Base-T |
| IEEE 802.3z Gigabit Fiber IEEE 802.3x Flow Control and Back Pressure | |
| IEEE 802.3ad Port Trunk with LACP IEEE 802.1d Spanning Tree/ IEEE 802.1x Rapid Spanning Tree | |
| IEEE 802.1p Class of Service IEEE 802.1Q VLAN Tag | |
| IEEE 802.1x User Authentication (Radius) IEEE 802.1ab LLDP | |
| 8 x 10/100Mpbs RJ-45 ports 2 x 10/100/1000Mbps RJ-45 ports | |
| 2 x Shared SFP slots RS-232 Connector (RJ-45 Type) | |
| Transfer Hızı | 10Mbps: 14,880pps 100Mbps: 148,800pps 1000Mbps: 1,488,000pps |
| Özellik | M-Ring, Dual Homing, Couple Ring Topology IEEE802.1w Rapid Spanning Tree Port Based VLAN, |
| IEEE 802.1Q VLAN (256 entries)/VLAN ID, | |
| GVRP (256 Groups) Port Trunk with LACP (4 Trunk groups & members) | |
| Flow Control for Full-duplex and | |
| Back Pressure for Half-duplex 3 Port Mirror types: RX, | |
| TX and Both packet IGMP snooping v1/v2, 256 multicast groups and | |
| IGMP query DHCP Client/DHCP Server DNS Client and | |
| Primary/Secondary DNS server SNTP to synchronize system clock in Internet | |
| MAC Address Table | 8K |
| Hardware | Back-plane (Switching Fabric): 5.6Gbps Packet throughput ability |
| (Full-Duplex): 8.3Mpps @64bytes Packet Buffer: 1Mbits Flash ROM: 4Mbytes DRAM: 32Mbytes | |
| Yönetim | DIN Rail and Wall Mount Design |
| SNMP/ Web/ Telnet/ CLI/ NS-View Management System Log, SMTP, | |
| Relay Alarm, SNMP Trap, TFTP firmware update | |
| Çevresel | Çalışma Sıcaklığı: -10 ~ 60 |
| Boyutlar, W x D x H | 72 x 105 x 152 mm |
| Güç | DC 12-48V, redundant power with polarity reverse protection 9.5Watts Power Consumption |
| Emisyon | CE, FCC |
Micronet SP6310IC2 Endüstriyel PoE Switch Pdf Dosyası1.01 MB
Teknik Kısa
PoE : PoE
Port Hızı : 100 Mbps
Yönetilebilirlik : Yönetilebilir Layer 2 Plus
Aktarım Port Sayısı : 2
Aktarım Türü : Combo
PoE Port Sayısı :
9 Port
9 Port PoE Güç Bütçesi : 130-200 Watt
Montaj Tipi : Wall Mount
