Açıklama
ONV ONV-H3108P PoE Switch
Özellikler
Teknik Özellikler
| Model | ONV-H3064P | ONV-H3108P |
| Interface Characteristics | ||
| Fixed Port | 4*10/100/1000Base-T PoE ports (Data/Power) | 8*10/100/1000Base-T PoE ports (Data/Power) |
| 2*10/100/1000Base-T uplink RJ45 ports (Data) | 2*10/100/1000Base-T uplink RJ45 ports (Data) | |
| Ethernet Port | Port 1-6/ Port 1-10 support 10/100/1000Base-T auto-sensing, full/half duplex MDI/MDI-X self-adaption | |
| Twisted Pair Transmission | 10BASE-T:Cat3,4,5 UTP(≤100 meter) | |
| 100BASE-TX:Cat5 or later UTP(≤100 meter) | ||
| 1000BASE-T : Cat5e or later UTP(≤100 meter) | ||
| Chip Parameter | ||
| Network Protocol | IEEE802.3 10BASE-T, IEEE802.3i 10Base-T | |
| IEEE802.3u 100Base-TX, IEEE802.3ab 1000Base-T, IEEE802.3x | ||
| Forwarding Mode | Store and Forward(Full Wire Speed) | |
| Switching Capacity | 16Gbps (Non-blocking) | 20Gbps (Non-blocking) |
Forwarding Rate@64byte | 8.93Mpps | 14.88Mpps |
| MAC | 8K | 2K |
| Buffer Memory | 2M | |
| Jumbo Frame | 9.2k | |
| LED Indicator | Power: PWR (Green), Network: Link (Green), PoE: PoE (Green) | |
| PoE & Power Supply | ||
| PoE Port | Port 1 to 4 | Port 1 to 8 |
| Power Supply Pin | Default 1/2(+), 3/6(-) | |
| Max Power Per Port | 30W, IEEE802.3af/at | |
| Total PWR / Input Voltage | 65W/ (AC100-240V) | 120W/ (AC100-240V) |
| Power Consumption | Standby <5W, Full load <65W | Standby <6W, Full load <120W |
| Power Supply | Built-in power supply, AC100~240V 50-60Hz 1.1A | Built-in power supply, AC100~240V 50-60Hz 2.2A |
| Physical Parameter | ||
| Operation TEMP / Humidity | -20~+55°C,5%~90% RH Non condensing | |
| Storage TEMP / Humidity | -40~+75°C, 5%~95% RH Non condensing | |
| Dimension (L*W*H) | 195*130*40mm | 195*130*40mm |
| Net /Gross Weight | <0.6kg / <1kg | <0.9kg / <1.2kg |
| Installation | Desktop, wall-mounted | |
| Certification & Warranty | ||
| Lightning Protection | Lightning protection: 4KV 8/20us, Protection level: IP30 | |
| Certification | CCC, CE mark, commercial, CE/LVD EN60950, FCC Part 15 Class B, RoHS | |
| Warranty | 1 year, lifelong maintenance. | |
Teknik Kısa
PoE : PoE
Port Hızı : 1 GBit
Yönetilebilirlik : Yönetilemez
Aktarım Port Sayısı : 2
Aktarım Türü : Rj45
Montaj Tipi : Desk Mount
PoE Port Sayısı :
8 Port
8 Port PoE Güç Bütçesi : 50-130 Watt
