Planet GSD-1121XP Gigabit PoE Switch

Teknik Özellikler

Hardware Specifications
Copper Ports	8 x 10/100/1000BASE-T RJ45
	- With 802.3at/af PoE+ injector function
	- Auto-MDI/MDI-X, auto-negotiation
	2 x 100/1000/2500BASE-T RJ45
	- With 802.3at/af PoE+ injector function
	- Auto-MDI/MDI-X, auto-negotiation
SFP+ Port	1 x 10GBASE-X SFP+ interface
Dimensions (W x D x H)	280 x 213 x 45mm
Weight	1711g
Power Requirements	100~240V AC, 50/60Hz
Installation	Desktop or rack-mount installation
Power Consumption / Dissipation	124 watts @ AC 110V
Power Consumption / Dissipation	125 watts @ AC 240V
ESD Protection	6KV contact/8KV air
EFT Protection	1KV
LED Indicators	1 x LED for Power:
	- Green: AC Power
	2 x LED for Per Copper Port (Port-1~Port-8):
	- Green: 10/100/1000 LNK/ACT
	- Amber: PoE-in-Use
	2 x LED for Per Copper Port (Port-9~Port-10):
	- Green: 100/1000/2500 LNK/ACT
	- Amber: PoE-in-Use
	1 x LED for SFP+ interface (Port-11)
	- Amber: 10G LNK/ACT
Switching Specification
Switch Processing Scheme	Store-and-Forward
Switch fabric	46Gbps
Throughput (packet per second)	34.2Mpps @64 bytes
Address Table	16K entries
Jumbo Frame	9600 Bytes
Flow Control	Back pressure for half duplex
Flow Control	IEEE 802.3x pause frame for full duplex
Power over Ethernet
PoE Standard	IEEE 802.3af/at PoE Plus, PSE
PoE Power Supply Type	End-span
PoE Power Output	Per port 52V DC, max. 30 watts
Power Pin Assignment	1/2 (+), 3/6 (-)
PoE Power Budget	120 watts
Standards Conformance
Standards Compliance	IEEE 802.3 Ethernet
	IEEE 802.3u Fast Ethernet
	IEEE 802.3ab Gigabit Ethernet
	IEEE 802.3ae 10Gb/s Ethernet
	IEEE 802.3af Power over Ethernet
	IEEE 802.3at Power over Ethernet Plus
	IEEE 802.3x Full-Duplex Flow Control
	IEEE 802.3az EEE (Energy Efficient Ethernet)
	IEEE 802.3bz 2.5GBASE-T
Regulatory Compliance	FCC Part 15 Class B, CE
Environment
Operating	Temperature: 0 ~ 50 degrees C
Operating	Relative Humidity: 5 ~ 95% (non-condensing)
Storage	Temperature: -10 ~ 70 degrees C
Storage	Relative Humidity: 5 ~ 95% (non-condensing)
