D-Link DWS 3026E Gigabit WLAN PoE Switch
Teknik Özellikler
| Genel Özellikler: |
| Device Interfaces |
| 24 10/100/1000BASE-T Gigabit Ports With Integrated 802.3af PoE |
| 4 Combo SFP Slots |
| RS-232 Console Port |
| 2 Open Slots for Optional 10-Gigabit Module1 |
| Redundant Power Supply |
| Connector for Optional External DPS-600 RPS |
| Power over Ethernet |
| Standard: 802.3af |
| Per Port Voltage Output: 15.4 W |
| Total Voltage Output: 370 W |
| Auto Disable If Port Current Over 350mA |
| Performance |
| Switch Capacity: 88Gbps |
| Maximum Forwarding Rate: 65.47Mpps |
| Switching Method: Store and Forward |
| Packet Buffer Memory Size: 750KBytes |
| Flow Control |
| 802.3x Standard in Full Duplex Mode |
| Back Pressure in Half Duplex Mode |
| Optional 10-Gigabit Uplink Modules1 |
| DEM-410X 1-Slot 10-Gigabit XFP Module |
| (For Fiber Backbone Attachment) |
| DEM-410CX 1-Port 10-Gigabit CX4 Module |
| (For Switch Cascading) |
| Optional 10-Gigabit XFP Transceivers 1 |
| DEM-421XT XFP Transceiver |
| (10GBASE-SR Standard, Up to 300 m Multi-Mode Fiber Distance, 3.3/5V Operating Voltage) |
| DEM-422XT XFP Transceiver |
| (10GBASE-LR Standard, Up to 10 km Single-Mode Fiber Distance, 3.3/5V Operating Voltage) |
| DEM-423XT XFP Transceiver |
| (10GBASE-ER Standard, Up to 40 km Single-Mode Fiber. Distance, 3.3/5V Operating Voltage) |
| WLAN Management Capability |
| Up to 48 AP (Directly connected or indirectly connected through LAN switch) |
| Up to 2,048 Wireless Users (1,024 Tunneled Users, 2,048 Non-Tunneled Users) |
| Roaming |
| Fast Roaming2 |
| Intra-Switch/Inter-Switch Roaming |
| Intra-Subnet/Inter-Subnet Roaming |
| Access Control & Bandwidth Management |
| Up to 16 SSID per AP (8 SSID per RF Frequency Band) |
| AP Load Balancing based on the number of users or utilization per AP |
| Managed AP |
| DWL-3500AP |
| DWL-8500AP |
| AP Management |
| AP Auto-Discovery |
| Remote AP Reboot |
| AP Monitoring: List Managed AP, Rogue AP, Authentication Failed AP |
| Client Monitoring: List Clients Associated with Each Managed AP |
| Ad-hoc Clients Monitoring |
| AP Authentication Supporting Local Database and External RADIUS Server |
| Centralized RF/Security Policy Management |
| Automatic AP RF Channel Adjustment |
| Automatic AP Transmit Output Power Adjustment |
| WLAN Security |
| WPA Personal/Enterprise |
| WPA2 Personal/Enterprise |
| 64/128/152-bit WEP Data Encryption |
| Wireless Station and AP Monitoring on RF Channel, MAC Address, SSID, Time |
| Rogue and Valid AP Classification Based on MAC Address |
| Encryption Type Support: WEP, WPA, Dynamic WEP, TKIP, AES-CCMP, EAP-FAST, EAP-TLS, EAP-TTLS, EAP-MD5, PEAP-GTC, PEAP-MS-CHAPv2, AP-TLS |
| Captive Portal |
| MAC Authentication |
| Station Isolation |
| L2 Features |
| MAC Address Table Size: 8K Entries |
| IGMP Snooping: 1K Multicast Groups |
| Spanning Tree: |
| 8021.D Spanning Tree |
| 802.1w Rapid Spanning Tree |
| 802.1s Multiple Spanning Tree |
| 802.3ad Link Aggregation: |
| Up to 32 Groups |
| Up to 8 Ports per Group |
| 802.1ab LLDP |
| Port Mirroring: |
| One-to-One Port Mirroring |
| Many to One Port Mirroring |
| Jumbo Frame Size: Up to 9KBytes |
| VLAN |
| 802.1Q VLAN Tagging |
| VLAN Groups: Up to 3965 |
| 802.1V |
| Subnet-based VLAN |
| MAC-based VLAN + GVRP |
| Double VLAN |
| L3 Features |
| IPv4 Static Yol Tarifi Göster |
| Routing Table Size: Up to 128 Static Routes |
| Floating Static Yol Tarifi Göster |
| VRRP |
| Proxy ARP |
| Quality of Service |
| 802.1p Priority Queues (Up to 8 Queues per Port) |
| CoS Based on: Switch Port, VLAN, DSCP, TCP/UDP Port, TOS, Destination/Source MAC Address, Destination/Source IP Address |
| Minimum Bandwidth Guarantee per Queue |
| Traffic Shaping per Port |
| ACL (Access Control List) |
| ACL Based on: Switch Port, MAC Address, 802.1p Priority Queues, VLAN, Ethertype, DSCP, IP Address, Protocol Type, TCP/UDP Port |
| LAN Security |
| RADIUS Authentication for Management Access |
| TACACS+ Authentication for Management Access |
| SSH v1, v2 |
| SSL v3 , TLS v1 |
| Port Security: |
| 20 MAC Addresses per Port |
| Trap Violation Notification |
| MAC Filtering |
| 802.1X Port-Based Access Control and Guest VLAN |
| Denial of Service Protection |
| Broadcast Storm Control in Granularity of 1% of Link Speed |
| Protected Port |
| DHCP Filtering |
| Management Methods |
| Web-Based GUI |
| CLI |
| Telnet Server: Up to 5 Sessions |
| Telnet Client |
| TFTP Client |
| SNMP v1, v2c, v3 |
| Multiple Configuration Files |
| RMON v1: 4 Groups (Statistics, History, Alarms, Events) |
| BOOTP/DHCP Client |
| DHCP Server |
| SNTP |
| SYSLOG |
| Dual Images |
| 1 Applicable to DWS-3026 switch only. |
| 2 To demonstrate fast roaming in a PC, a wireless NIC (Network Interface Card) needs to support the fast roaming feature. |
| Fiziksel Özellikler |
| Diagnostic LEDs |
| Per Device: Power, Console, RPS |
| Per 10/100/1000BASE-T Port: Link/Activity/Speed, PoE Mode |
| Per SFP Slot: Link/Activity |
| Per 10-Gigabit Slot: Link/Activity1 |
| Power |
| AC Input Power: 100 to240 VAC, 50/60 Hz Internal Universal Power Supply |
| Power Consumption: 460 Watts (max. with all PoE ports in operation) |
| MTBF |
| 173,071 hours |
| Heat Dissipation |
| Heat Dissipation: 1569.61 BTU/hr |
| Ventilation DC Fans: 440 x 40 mm DC Fans |
| Dimensions |
| 440 (W) x 389 (D) x 44 (H) mm |
| (17.32 x 15.31x 1.73 inches) |
| 19-Inch Standard Equipment Rack Mount Width, 1U Height |
| Weight |
| 6kg (13.23 lbs) |
| Temperature |
| Operating Temperature: 0° to 40° C (32° to 104° F) |
| Storage Temperature: -10° to 70° C (14° to 158° F) |
| Humidity |
| Operating Humidity: 10% to 90% non-condensing |
| Storage Humidity: 5% to 90% non-condensing |
| EMI/EMC Certification |
| FCC Class A |
| ICES-003 |
| VCCI |
| CE |
| C-Tick |
| EN 60601-1-2 |
| Safety Certification |
| UL/cUL |
| CB |
D-Link DWS 3026E Gigabit WLAN PoE Switch Pdf Dosyası485.85 KB
Teknik Kısa
PoE : PoE
Port Hızı : 1 GBit
Yönetilebilirlik : Yönetilebilir Layer 2 Plus
Aktarım Port Sayısı : 4
Aktarım Türü : Combo
PoE Port Sayısı :
24 Port
24 Port PoE Güç Bütçesi : 200-400 Watt
Montaj Tipi : Rack Mount
