Hikvision DS 3D2228P PoE Switch
Özellikler
Excellent performance
- 64Gbps backplane capacity; non-blocking design; video streaming forwardingat full speed;
- Gigabit optical-fiber transmission with up to 120Km distance;
High security and reliability
- Providing multiple user authentication modes such as 802.1x authentication;
- Port-MAC-IP bind;
- Special ARP invasion detection to effectively stop ARP cheat;
Flexible and various managements
- Adopt cluster technology, support device stacking and use an unified IP address for management;
- Multiple management modes such as Console port, Telnet, Web and SNMP;
Powerful flow and broadcast management
- Automatically detecting and controlling broadcast storms, monitoring IGMP packets and effectively preventing broadcast packet's flooding;
- Flow control in full-duplex mode or half-duplex mode;
- The rate limitation in a minimum step of 64K is supported on the Ethernet port;
- IP multicast and QoS;
Varied protocols
- 802.3af power supply on all ports;
- 802.3at power supply with the maximum power supply on each port reaching up to 30W;
- Configurable power supply priority guarantees, continuous power supply at key network nodes;
- Configurable power consumption to save power and users' cost.
Teknik Özellikler
| Parameter | |
| Port | 24 100M Ethernet Ports |
| 4 1000M Ethernet Ports | |
| 4 1000M SFP Optical Multiplex Ports | |
| 1 Console port | |
| Backplane Capacity | 64Gbps |
| Switching Bandwidth | 32Gbps |
| Forwarding | 9.6Mpps |
| MAC Table | 8K |
| Video Buffering | 64MB |
| STP | IEEE 802.1D STP |
| IEEE 802.1w RSTP | |
| IEEE 802.1s MSTP | |
| VLAN | Port-based VLAN |
| 802.1Q VLAN | |
| GVRP | |
| VLAN No | 4K (any division) |
| QinQ | Support |
| QoS | Support |
| Flow Control | Backpressure is adopted for half-duplex, while IEEE802.3x is adopted for full-duplex. |
| Multicast | IGMP Snooping |
| Network Management | SNMP, Telnet, RMON, CLI, support multiple SNMP network management software |
| Network Security | IEEE 802.1x |
| Port access control | |
| IP ACL, MAC ACL and VLAN ACL | |
| DHCP snooping | |
| DAI and static/dynamic ARP prevention | |
| RADIUS | |
| Dimension | 442mm×315mm×44mm |
| (17.40”×12.40”×1.73”) | |
| Power Source | 110-240VAC (self-adaptive), 47-63Hz, 1A/230V |
| PoE/PoE+ power supply | |
| Power Consumption | Max. 400W (including PoE power supply), support 802.3af power supply on 24 ports or 802.3at power
supply on 12 ports |
| Indicator | Power indicator, system indicator, connection/data forwarding indicator, 10/100M indicator |
| Environment | Working temperature: 0 °C ~55 °C (32 °F ~ 131 °F) |
| Humidity: 0-90% (no condensation) | |
| SFP modules | HK-1.25G-20-1550: 1000M SFP module, TX1550nm/RX1310nm, LC, single-mode single-fiber, 20km |
| HK-155M-20-1550: 100M SFP module, TX1550nm/RX1310nm, LC, single-mode single-fiber, 20km | |
Teknik Kısa
PoE : PoE
Port Hızı : 100 Mbps
Yönetilebilirlik : Yönetilebilir
Aktarım Port Sayısı : 4
Aktarım Türü : Combo
PoE Port Sayısı :
24 Port
24 Port PoE Güç Bütçesi : 200-400 Watt
