Planet SGS-5240-24P4X Layer 2+ PoE Switch
Teknik Özellikler
| Hardware Specifications | |
| 10/100/1000BASE-T RJ45 Ports | 24 |
| 1000BASE-X SFP Slots | - |
| 10GBASE-X SFP+ Slots | 4 10GBASE-SR/LR SFP+ interfaces |
| Compatible with 1000BASE-SX/LX/BX SFP transceiver | |
| Console | 1 x RJ45-to-RS232 serial port (115200, 8, N, 1) |
| CPU | ARM A9 800MHz |
| RAM | 512Mbytes |
| Flash Memory | 64Mbytes |
| Dimensions (W x D x H) | 440 x 280 x 44 mm |
| Weight | 4.1 kg |
| Power Consumption | 432 watts/1474 BTU |
| Power Requirements - AC | AC 100~240V, 50/60Hz |
| Power Requirements - DC | - |
| Fan | 2 |
| Switching | |
| Switch Architecture | Store-and-forward |
| Switch Fabric | 128Gbps/ |
| non-blocking | |
| Switch Throughput | 95.23Mpps |
| Address Table | 16K MAC address table with auto learning function |
| ARP Table | 1024 |
| ACL Table | 900 |
| Shared Data Buffer | 1.5MB |
| Jumbo Frame | 9KB |
| Flow Control | Back pressure for half duplex |
| IEEE 802.3x pause frame for full duplex | |
| Power over Ethernet Specifications | |
| PoE Standard | IEEE 802.3at Power over Ethernet Plus PSE |
| Backward compatible with IEEE 802.3af PoE | |
| PoE Power Supply Type | End-span |
| PoE Power Output | Per port 54V DC, maximum 30 watts |
| Power Pin Assignment | 1/2(+), 3/6(-) |
| PoE Power Budget | 370 watts (max.) |
| Layer 3 Functions | |
| IP Interfaces | Max. 32 VLAN interfaces |
| Routing Table | IPv4 256 entries |
| IPv6 128 entries | |
| Routing Protocols | IPv4 hardware static routing |
| IPv6 hardware static routing | |
| Layer 2 Functions | |
| Port Configuration | Port disable/enable |
| Auto-negotiation 10/100/1000Mbps full and half duplex mode selection | |
| Flow control disable/enable | |
| Port loopback detect | |
| Port Status | Display each port’s speed duplex mode, link status, flow control status and auto negotiation status |
| Port Mirroring | TX/RX/Both |
| Remote port mirror (RSPAN) | |
| Many-to-1 monitor | |
| VLAN | IEEE 802.1Q tagged based VLAN, up to 4K VLAN groups |
| IEEE 802.1ad Q-in-Q VLAN stacking/tunneling | |
| IEEE 802.1v Protocol-based VLAN | |
| Port-based VLAN | |
| MAC-based VLAN | |
| IP Subnet-based VLAN | |
| Voice VLAN | |
| GVRP for VLAN management, up to 256 VLAN | |
| Spanning Tree Protocol | IEEE 802.1D Spanning Tree Protocol (STP) |
| IEEE 802.1w Rapid Spanning Tree Protocol (RSTP) | |
| IEEE 802.1s Multiple Spanning Tree Protocol (MSTP) | |
| BPDU Guard, BPDU filtering and BPDU transparent | |
| Root Guard | |
| STP-based loopback detection | |
| Multicast | IPv4 IGMP v1/v2/v3 snooping |
| IPv4 Querier mode support | |
| IGMP Filtering and IGMP Throttling | |
| IGMP Proxy reporting | |
| IGMP mroute-forward mode | |
| Up to 255 multicast groups | |
| IPv6 MLD v1/v2 snooping | |
| Up to 255 multicast groups | |
| Multicast VLAN Register (MVR), supports 5 multicast VLANs | |
| Link Aggregation | IEEE 802.3ad Ling Aggregation Control Protocol (LACP) |
| Static trunk link aggregation | |
| Supports 26 groups with 8 ports per trunk group | |
| Up to 80Gbps bandwidth (full duplex mode) | |
| Load Balance Algorithm: | |
| - Source IP/destination IP/Source + destination IP | |
| - Source MAC/destination MAC/Source + destination MAC | |
| Storm Control | Broadcast/Multicast/Unicast storm control |
| Rate: 64Kbpss-10,000Mbps | |
| Bandwidth Control | Input/Output/Both |
| Per port bandwidth control | |
| Gigabit port: 64Kbpss-1,000Mbps | |
| 10Gigabit port: 64Kbpss-10,000Mbps | |
| QoS | 8 priority queues on all switch ports |
| Scheduling for priority queues | |
| - Weighted Round Robin (WRR) | |
| - Strict priority | |
| - Hybrid (DRR/WRR + strict) | |
| Traffic classification: | |
| - IEEE 802.1p CoS/DSCP/IP Precedence | |
| - VLAN ID | |
| - ACL | |
| - Policy-based ingress and egress QoS | |
| Ring | ITUT G.8032 ERPS v1 and v2 |
| Security Functions | |
| Access Control List | Supports Standard and Expanded ACL |
| - IP-based ACL | |
| - MAC-based ACL | |
| - ARP ACL | |
| - Time-based ACL | |
| ACL based on: | |
| - MAC Address | |
| - IPv4/IPv6 IP Address | |
| - Ethertype | |
| - Protocol-number/UDP | |
| - sport/dport | |
| - DSCP | |
| - 802.1p Priority | |
| Up to 900 entries | |
| Security | Port security |
| Supports static MAC + port binding | |
| Defend against DoS or TCP attacks | |
| DHCP Snooping, DHCP Option 82 | |
| IP source guard | |
| Dynamic ARP inspection | |
| Command line authority control based on user levels | |
| AAA | RADIUS client |
| TACACS+ client | |
| Network Access Control | IEEE 802.1x port-based network access control |
| MAC-based authentication | |
| Web authentication | |
| Local/RADIUS authentication | |
| Management Functions | |
| System Configuration | Console and Telnet |
| Web browser | |
| SNMP v1, v2c | |
| Secure Management Interfaces | IPv4/IPv6 SSHv2, SSLv3, SNMPv3 |
| Maximum 8 sessions for SSH and telnet connection | |
| System Management | IPv4 and IPv6 dual stack management |
| SNMP MIB and TRAP | |
| SNMP RMON 1, 2, 3, 9 four groups | |
| Firmware upgrade by HTTP/TFTP/FTP protocol through Ethernet network | |
| Configuration upload/download through HTTP/TFTP/FTP protocol | |
| Supports dual images and multiple configuration files | |
| Supports IEEE 802.1ab LLDP protocol | |
| NTP/SNTP client | |
| RADIUS authentication for IPv4/IPv6 login user name and password | |
| Security IP safety net management function: avoid unlawful landing at nonrestrictive area | |
| Event Management | Remote Syslog |
| System log | |
| SMTP | |
| IP Clustering | 16 members |
| IP Clustering Compatibility List | SGS-5240-24T4X |
| SGS-5240-24P4X | |
| SGS-5240-20S4C4XR | |
| SGS-5240-48T4X | |
| Hardware Stacking | 6 members max. |
| Last 2 10G SFP+ slots are functioned as Stacking Up and Down interfaces | |
| SNMP MIBs | RFC 1213 MIB-II |
| RFC 1215 Internet Engineering Task Force | |
| RFC 1271 RMON | |
| RFC 1354 IP-Forwarding MIB | |
| RFC 1493 Bridge MIB | |
| RFC 1643 Ether-like MIB | |
| RFC 1907 SNMP v2 | |
| RFC 2011 IP/ICMP MIB | |
| RFC 2012 TCP MIB | |
| RFC 2013 UDP MIB | |
| RFC 2096 IP forward MIB | |
| RFC 2233 if MIB | |
| RFC 2452 TCP6 MIB | |
| RFC 2454 UDP6 MIB | |
| RFC 2465 IPv6 MIB | |
| RFC 2466 ICMP6 MIB | |
| RFC 2573 SNMP v3 notify | |
| RFC 2574 SNMP v3 vacm | |
| RFC 2674 Bridge MIB Extensions (IEEE 802.1Q MIB) | |
| RFC 2674 Bridge MIB Extensions (IEEE 802.1P MIB) | |
| Standard Conformance | |
| Regulatory Compliance | FCC Part 15 Class A, CE |
| Standards Compliance | IEEE 802.3 10BASE-T |
| IEEE 802.3u 100BASE-TX | |
| IEEE 802.3z Gigabit 1000BASE-SX/LX | |
| IEEE 802.3ab Gigabit 1000BASE-T | |
| IEEE 802.3ae 10Gb/s Ethernet | |
| IEEE 802.3x flow control and back pressure | |
| IEEE 802.3ad port trunk with LACP | |
| IEEE 802.1D Spanning Tree Protocol | |
| IEEE 802.1w Rapid Spanning Tree Protocol | |
| IEEE 802.1s Multiple Spanning Tree Protocol | |
| IEEE 802.1p Class of Service | |
| IEEE 802.1Q VLAN tagging | |
| IEEE 802.1ad Q-in-Q VLAN stacking/tunneling | |
| IEEE 802.1v Protocol-based VLAN | |
| IEEE 802.1X port authentication network control | |
| IEEE 802.1ab LLDP | |
| IEEE 802.3at Power over Ethernet Plus | |
| IEEE 802.3af Power over Ethernet | |
| RFC 768 UDP | |
| RFC 793 TFTP | |
| RFC 791 IP | |
| RFC 792 ICMP | |
| RFC 2068 HTTP | |
| RFC 1112 IGMP v1 | |
| RFC 2236 IGMP v2 | |
| RFC 3376 IGMP v3 | |
| RFC 2710 MLD v1 | |
| FRC 3810 MLD v2 | |
| ITU-T G.8032 ERPS Ring | |
| Environments | |
| Operating | Temperature: 0 ~ 50 degrees C |
| Relative Humidity: 5 ~ 90% (non-condensing) | |
| Storage | Temperature: -10 ~ 70 degrees C |
| Relative Humidity: 5 ~ 90% (non-condensing) | |
Planet SGS-5240-24P4X, Layer 2+ PoE Switch Pdf Dosyası23.75 MB
Teknik Kısa
PoE : PoE Plus
Port Hızı : 1 GBit
Yönetilebilirlik : Yönetilebilir Layer 2 Plus
Aktarım Port Sayısı : 2
Aktarım Türü : Gbit Fiber
PoE Port Sayısı :
24 Port
