Planet GSD-504UP PoE Switch
Özellikler
RJ45 Interface
- 5 10/100/1000BASE-T RJ45 ports
- Complies with IEEE 802.3af/at/bt Power over Ethernet end-span PSE
- 2 ports for IEEE 802.3bt PDs and 2 ports for IEEE 802.3af/at PDs
- Supports PoE power up to 90 watts for PoE ports 1 to 2, 30 watts for PoE ports 3 to 4
- Each port supports 55V DC power to PoE PD
- 120-watt PoE budget
- Auto detects PD
- Circuit protection prevents power interference between ports
- Supports PoE in Standard and Legacy mode
Switching
- Hardware-based 10/100/1000Mbps auto-negotiation and auto MDI/MDI-X
- Flow control for full duplex operation and back pressure for half duplex operation
- Integrates address look-up engine, supporting 2K absolute MAC addresses
- Automatic address learning and address aging
Hardware
- LED indicators for PoE ready/activity and LINK/ACT
- One 55V DC power jack
- Fanless design
Teknik Özellikler
| Hardware Specifications | |
| Network Connector | 5 10/100/1000BASE-T RJ45 auto MDI/MDIX ports |
| PoE Inject Port | 2 ports with 802.3bt PoE++ injector function (Ports 1 to 2) |
| 2 ports with 802.3af/at PoE+ injector function (Ports 3 to 4) | |
| LED Indicators | System: PWR (Orange) |
| Per PoE port: PoE (Orange, Ports 1 to 4) | |
| Ethernet port: LNK (Green) | |
| Thermal Fan | Fanless design |
| Switch Architecture | Store-and-Forward |
| MAC Address Table | 2K MAC address table with auto learning function |
| Switch Fabric | 10Gbps |
| Switch Throughput | 7.44Mpps @64 bytes |
| Jumbo Packet | 9K bytes |
| Flow Control | Back pressure for half duplex. IEEE 802.3x |
| pause frame for full duplex | |
| Power Requirements | 55V DC, 2.8A |
| Surge Protection | Contact: 4KV; |
| Air: 6KV | |
| ESD Protection | Contact: 4KV; |
| Air: 6KV | |
| Power Consumption | Max. 136 watts, 464.05 BTU |
| Dimensions (W x D x H) | 168 x 93 x 32 mm |
| Weight | 414g |
| Power over Ethernet | |
| PoE Standard | IEEE 802.3at Power over Ethernet Plus/PSE |
| IEEE 802.3bt Power over Ethernet Plus Plus/PSE | |
| PoE Power Supply Type | Ports 1 to 2: End-span + Mid-span; |
| Ports 3 to 4: End-span | |
| Power Pin Assignment | Port 1-2: 4 pairs 1/2 (-), 3/6 (+) and 4/5 (+), 7/8 (-) |
| Port 3-4: 2 pairs 1/2 (-), 3/6 (+) | |
| PoE Power Output | Port 1-2: 90W max.; |
| Port 3-4: 30W max. | |
| Total PoE Power Budget | 120 watts |
| Standard Conformance | |
| EMI Safety | FCC Part 15 Class A, CE |
| Standard Compliance | IEEE 802.3 10BASE-T |
| IEEE 802.3u 100BASE-TX | |
| IEEE 802.3ab 1000BASE-T Gigabit 1000BASE-T | |
| IEEE 802.3x Flow Control and Back Pressure | |
| IEEE 802.3af Power over Ethernet | |
| IEEE 802.3at Power over Ethernet Plus | |
| IEEE 802.3bt Power over Ethernet Plus Plus | |
| Environment | |
| Operating | Temperature: 0 ~ 50 degrees C |
| Relative Humidity: 5 ~ 95% (non-condensing) | |
| Storage | Temperature: -10 ~ 70 degrees C |
| Relative Humidity: 5 ~ 95% (non-condensing) | |
Planet GSD-504UP PoE Switch Pdf Dosyası2.19 MB
Planet GSD-504UP PoE Switch Kullanım Kılavuzu (ing) Pdf Dosyası1.27 MB
Teknik Kısa
PoE : PoE Plus
Port Hızı : 1 GBit
Yönetilebilirlik : Yönetilemez
Aktarım Port Sayısı : 2
Aktarım Türü : Gbit Fiber
Montaj Tipi : Desk Mount
PoE Port Sayısı :
4 Port
4 Port PoE Güç Bütçesi : 50-130 Watt
