| CAMERA |
| Image Sensor | 1/2.7” Progressive Scan CMOS |
| Min. illumination | Color :0.2Lux@(F1.2,AGC ON);B/W: 0 Lux@(IR LED ON) |
| Day & Night | ICR |
| Shutter Speed | 1/5-1/20000 |
| Auto Iris | Fixed |
| Wide Dynamic Range | WDR >120dB |
| Digital Noise Reduction | 2D/3D |
| Lens | 2.8-12mm |
| FOV | 90°-35° |
| IR LED | 30pcs |
| IR Range | Up to 40m |
| IMAGE |
| Video Compression | H.265/H.264/ MJPEG |
| Bit Rate (CBR/VBR) | Main stream: 1080P: 500Kbps-12Mbps , |
| 720P: 200Kbps-8Mbps ; |
| Sub stream 100kbps-6000kbps |
| Audio Compression | G.711 ,RAW_PCM |
| Max. Resolution | 1920x1080/30fps |
| Stream | Stream 1 1920x1080 /1280x720 @25/30fps |
| Stream 2 D1/VGA / /640x 360 / CIF / QVGA @25/60fps |
| Stream 3 VGA / CIF / QVGA @25/30fps |
| Image Setting | Rotate Mode, Saturation, Brightness, Contrast, Sharpness |
| HLC | Yes |
| 9:16 Corridor mode | Yes |
| ROI | Yes |
| Defog | Yes |
| NETWORK |
| Network Protocols: | IPv4,IPv6,IEEE802.1x,HTTP,HTTPS,TCP/IP,UDP/IP,RTSP,DHCP,NTP, RTCP/RTP, PPPoE, SMTP, DNS, SNMP, FTP, ICMP ,IGMP |
| Alarm Trigger | Perimeter ,Single Virtual Fences ,Double Virtual Fences ,Loiter ,Multi Loiter ,Object Left ,Object Removed, Abnormal Speed ,Converse, Illegal Parking ,Signal Bad , Motion Detection, Network disconnect, |
| RTSP Video | Standard RFC2326, Support QuickTime / VLC Player. |
| Security | User security authentication, Reset, Hardware Watch Dog |
| Web Language | English, Chinese, Polish, Italian, Portuguese, Spanish. Russian, French, Czech, Hungarian (Sunell Brand) |
| System Compatibility | Onvif |
| Interface |
| Ethernet | 1 Ethernet (10/100 Base-T) RJ-45 Connector |
| Audio I/O | N/A |
| Alarm I/O | N/A |
| RS485 | N/A |
| BNC Output | N/A |
| Reset Button | N/A |
| Edge Storage | N/A |
| GENERAL |
| Power Supply | DC12V/POE IEEE802.3AF |
| Power Consumption | 2.5W(IR LED OFF)；5W（IR LED ON） |
| Operating Temperature | Starting Temperature: -10°C ~ 50°C (14°F ~ 122°F ) |
| Working Temperature: -20°C ~ 50°C (-4°F ~ 122°F) |
| Operating Humidity | 0% - 90% RH |
| Ingress Protection | IP66 |
| Approvals | CE / FCC |
| Product Dimensions | 277*80mm |
| Product Weight | 800g |
