Neutron IPC6222ER X30P B Speed Dome Kamera

Teknik Özellikler

  IPC6222ER-X30-B IPC6222ER-X30P-B
Camera
Sensor 1/2.8", 2.0 megapixel, progressive scan, CMOS
Lens 4.5 ~ 135mm, AF automatic focusing and motorized zoom lens
Digital Zoom 16
Optical Zoom 30
DORI Distance Lens (mm) Detect (m) Observe (m) Recognize (m) Identify (m)
4.5 69.8 27.9 14 7
135 2094.8 837.9 419 209.5
Angle of View (H) 71.7° ~ 2.4°
Angle of View (V) 43.4° ~ 1.3°
Angle of View (O) 88.2° ~ 2.8°
Shutter Auto/Manual; shutter time: 1 ~ 1/100000s
Minimum Illumination Colour: 0.001Lux (F1.5, AGC ON)
0Lux with IR
Iris Auto/Manual; F1.5 ~ F4.0
Day/Night IR-cut filter with auto switch (ICR)
Digital noise reduction 2D/3D DNR
S/N >52dB
IR Range Up to 150m (492ft)
Defog Digital Defog
WDR 120dB
Video
Video Compression Ultra 265, H.265, H.264, MJPEG
H.264 code profile Baseline profile, Main Profile, High Profile
Frame Rate Main Stream: 2MP (1920*1080), Max 30fps;
Sub Stream: 2MP (1920*1080), Max 30fps;
Third Stream: D1 (720*576), Max 30fps
HLC Supported
BLC Supported
EIS Supported
OSD Up to 8 OSDs
Privacy Mask Up to 24 areas
ROI Up to 8 areas
Motion Detection Up to 4 areas
Smart
Behavior Detection Intrusion, cross line, motion detection, auto tracking
Intrusion Enter and loiter in a pre-defined virtual region
cross line Cross a pre-defined virtual line
motion detection Moving within a pre-defined virtual region
auto tracking Tracking the specified target
Recognition Face detection, Audio detection
Intelligent Identification Object Left, Object Moving
Statistical Analysis People counting
General Function Watermark, IP Address Filtering, Tampering Alarm, Alarm input, Alarm output, Access Policy, ARP Protection, RTSP Authentication, User Authentication
Audio
Audio Compression G.711
Two-way audio Supported
Suppression Supported
Sampling Rate 8KHZ
Storage
Edge Storage Micro SD, up to 256GB
Network Storage ANR
Network
Protocols IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x, SNMP, QoS
Compatible Integration ONVIF (Profile S, Profile G, Profile T), API
Pan & Tilt
Pan Range 360° (endless)
Pan Speed 0.1°/s ~ 240°/s
Preset speed: 300°/s
Tilt Range –15° ~ 90° (auto reverse)
Tilt Speed 0.1° ~ 160°/s
Preset speed: 240°/s
Number of Presets 1024
Patrol Up to 16 patrols, up to 32 presets per patrol
Note: The total number of patrols and patterns is 16.
Home Position Supported
Interface
Audio I/O Audio cable
Input: impedance 35kΩ; amplitude 2V [p-p]
Output: impedance 600Ω; amplitude 2V [p-p]
Alarm I/O 1/1
Network 1RJ45 10M/100M Base-TX Ethernet
General
Power AC 24V±25%, DC 24V±25% AC 24V±25%, DC 24V±25%, PoE (PSE Required)
Power consumption: 9 ~ 42W
Dimensions (Ø x H) Ø227 x 359.4mm (Ø8.9” x 14.2”)
Weight 5.28kg (11.6lb)
Working Environment -40°C ~ 65°C (-40°F ~ 149°F), Humidity: ≤95% RH (non-condensing)
Ingress Protection IP66

Teknik Kısa

Depolama : Var
Çözünürlük : 2MP (1080P)
Ses : Var
