| Thermal Camera |
| Image Sensor | Uncooled VOx Microbolometer |
| Effective Pixels | 400(H)x300(V) |
| Pixel Size | 17um |
| Thermal Sensitivity(NETD) | 40mK@f/1.0 |
| Spectral Range | 7~14um |
| Image Setting | Brightness/Sharpness/ROI/AGC/FFC/3D DNR |
| Color Palettes | 14(Whitehot/Blackhot/Ironrow/Icefire/ |
| Fusion/Rainbow/Globow/Iconbow1/ |
| Iconbow2 .etc) |
| Thermal Lens |
| Lens Type | Fixed |
| Focus Control | Athermalized, Focus-free |
| Focal Length | 7.5mm | 13mm | 19mm | 25mm | 35mm |
| Angle of View | H: 52° | H: 29.7° | H: 20.4° | H: 15.5° | H: 11.1° |
| V: 40° | V: 22.3° | V: 15.3° | V: 11.6° | V: 8.3° |
| Effective Distance① | D②: 240m | D: 450m | D: 640m | D: 1000m | D: 1300m |
| Man(1.8m*0.5m) | R③: 60m | R: 110m | R: 160m | R: 250m | R: 320m |
| I ④: 30m | I: 60m | I: 80m | I: 125m | I: 160m |
| Effective Distance | D: 720m | D: 1300m | D: 2000m | D: 3000m | D: 4000m |
| Vehicle(2.3m*2.3m) | R: 180m | R: 350m | R: 500m | R: 720m | R: 1000m |
| I: 90m | I: 180m | I: 250m | I: 360m | I: 500m |
| Compression | H.264/MJPEG |
| Frame Rate | Main Stream: |
| 1280*1024 (default)/720P @1 ~ 25/30fps |
| Sub Stream: |
| 640*512 (default)/320*256 @1 ~ 25/30fps |
| Bit Rate Control | CBR/VBR |
| Bit Rate | H.264: 640 ~ 8192Kbps |
| Motion Detection | Off/On (4 zone, Rectangle) |
| Region of Interest | Off/On (4 zone) |
| Electronic Image Stabilization | NA |
| (EIS) |
| Digital Zoom | 19x |
| Flip | 180° |
| Mirror | Off/On |
| Privacy Masking | Off/On (4 area, Rectangle) |
| Audio |
| Compression | G.711a/G.711Mu/AAC |
| Intelligence |
| IVS | Tripwire, Intrusion, Object Abandon/Missing |
| Advanced Intelligent Functions | Fire detection & alarm |
| Network |
| Ethernet | RJ-45 (10/100Base-T) |
| Protocol | IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS, Bonjour, 802.1x |
| Interoperability | ONVIF Profile S & G, PSIA, CGI |
| Streaming Method | Unicast/Multicast |
| Max. User Access | 10 Users/20 Users |
| Edge Storage | Micro SD (256GB) |
| Memory status display (Normal / Error / Active / Formatting / Lock), |
| NAS (Network Attached Storage), Local PC for instant recording |
| Web Viewer |
| Management Software | SmartPSS, DSS |
| Smart Phone | Android, Ios |
| Certifications |
| Certification | CE (EN 60950: 2000) FCC (FCC Part 15 SubpartB ) |
| Interface |
| Video Interface | 1.0Vp-p/75Ω, PAL / NTSC (HDCVI Optional) |
| Audio Interface | 1/1 In/Out |
| RS485 | Support |
| Alarm | 2/1 In/Out |
| Electrical |
| Power Supply | AC 24V/DC 12V/PoE |
| Power Consumption | Max. 11W |
| Environmental |
| Operating Condition | -40°C ~ +60°C (-40°F ~ +140°F)/Less than 95% RH |
| * Start up should be done at above -40°C (-40°F) |
| Storage Conditions | -40°C ~ +70°C (-40°F ~ +158°F)/Less than 95% RH |
| Ingress Protection | IP67 |
| Construction |
| Casing | Metal |
| Dimensions | 291mm× 103mm× 97mm (11.46" x 4.06" x 3.82") |
| Net Weight | 1.5Kg (3.31 lb) |
| Gross Weight | 1.9Kg (4.19 lb) |
