| Thermal Camera |
| Detector Type | Uncooled IRFPA Microbolometer |
| Effective Pixels | 400(H) ×300(V) |
| Pixel Size | 20um |
| Thermal Sensitivity (NETD) | 50mK @F1.0, 300K |
| Spectral Range | 8~14um |
| Image Setting | Polarity LUT/ DVE/ Mirror/ FCC/ /3D DNR Brightness/Contrast/ ROI |
| Color Palettes | Black-Heat /White-Heat/Rainbow/Iron-Red up to 17 modes |
| Thermal Lens |
| Lens Type | Fixed |
| Focus Control | Motorize Focus |
| Focal Length | 25mm | 50mm | 75mm | 100mm |
| F No. | F1.0 | F1.0 | F1.0 | F1.0 |
| Angle of View | H: 14.6° | H: 7.3° | H: 4.8° | H: 3.6° |
| V:11° | V:5.5° | V:3.6° | V:2.7° |
| Temperature Detect Distance Fire(0.8m*0.8m) | 500m | 1000m | 1500m | 2000m |
| Recognition Distance Man(1.8m*0.5m) | 375m | 750m | 1120m | 1500m |
| Recognition Distance Vehicle(2.3m*2.3m) | 830m | 1660m | 2500m | 3300m |
| Video and Audio |
| Compression | H.265, H.264, MJPEG |
| Frame Rate | Main Stream: D1 @25/30fps |
| | Sub Stream: CIF @25/30fps |
| Bit Rate Control | CBR/VBR |
| Bit Rate | 100Kbps~6Mbps |
| Region of Interest | Off / On (8 Zone, Rectangle) |
| Electronic Image Stabilization(EIS) | N/A |
| Digital Zoom | 16x |
| Mirror | Support |
| Defog | Support |
| Motion Detection | Support |
| Privacy Masking | Off / On (4 Area, Rectangle) |
| DVE Image Enhance | Support |
| Audio Compression | G.711, AMR, RAW_PCM (Optional) |
| Intelligence |
| Intelligent Functions | Motion detection, Disk alarm, I/O alarm, Temperature alarm |
| IVS | Perimeter ,Single Virtual Fences ,Double Virtual Fences ,Object Left ,Object Removed |
| PTZ |
| Pan/Tilt Range | Pan: ° ~ 360° endless; Tilt: +40° ~ -75° |
| Pan/Tilt Speed | Pan: 0.01° ~60° /s; Tilt: 0.01° ~30° /s |
| Preset Speed | Pan: 0.01° ~60° /s; Tilt: 0.01° ~30° /s |
| Presets | 400 |
| PTZ Mode | 8 Auto Scan, 12 Tour, 6 Track |
| Speed Setup | Auto/Manual (0-8), |
| Power Off Memory | Support |
| Idle Motion | Activate Preset/ Scan/ Tour/ Pattern if there is no command in the specified period |
| Protocol | SN-SD, Pelco-D |
| Temperature Detection |
| Temperature Detection | Point detection, Area detection |
| Temperature Alarm | Over temperature alarm, Temperature difference alarm |
| Precision | Max (±2℃, ±2%) |
| Detection Area | Support 8 areas (8 target) |
| Response Time | ≤30ms |
| Effective temperature working environment | -10 °C ~ 55 °C (14°F ~ 131 °F) |
| Theory of temperature measurement range | -30 °C ~ 200 °C (-22°F ~ 392 °F) |
| Temperature display mode | Temperature target ＞5℃, Display absolute temperature value; |
| Temperature target ≤5℃, Display relative temperature value (temperature difference DEV = highest value - average) |
| Network |
| Ethernet | RJ-45 (10/100Base-T) |
| Protocols: | IPv4/IPv6 ,HTTP,RTSP/RTP/RTCP, TCP/UDP, DHCP, DNS, PPPOE, SMTP, SIP ,802.1x |
| Interoperability | ONVIF, CGI |
| Streaming Method | Unicast |
| Max. User Access | 10 Users |
| Edge Storage | NAS |
| Local PC for instant recording |
| Mirco SD card 128GB |
| Web Viewer | |
| Web Language | English, Chinese, Polish, Italian, Portuguese, Spanish. Russian, French, Czech, Hungarian |
| Interface |
| Ethernet | 1 Ethernet (10/100 Base-T) RJ-45 Connector |
| Audio Interface | 1ch Audio In,1ch Audio Out |
| Alarm | 2ch Alarm In,2ch Alarm Out |
| RS485 | Support |
| BNC Output | Support |
| Reset Button | Support(Built-in) |
| General |
| Power Supply | AC24V/DC24V |
| Power Consumption | Max 100W |
| Operating Temperature | -25 °C ~ 55 °C (-13 °F ~ 131 °F) |
| Strorage Conditions | 0~ 90% RH |
| Certifications | CE /FCC |
| Ingress Protection | IP66 |
| Casing | Metal |
| Dimensions | 585×251×502mm |
| Net Weight | 21Kg (Contains 50 mm lens) |
