| Camera |
| Image Sensor | 1/2.8" Progressive Scan CMOS |
| Effective Pixels | 1920(H)x1080(V) |
| İşaret Sistemi | PAL/NTSC |
| Minimum Aydınlatma | Color 0.005 Lux @(F1.6, AGC ON) |
| B/W 0.001 Lux @(F1.6, AGC ON) |
| White Balance | AUTO/MANUAL/HAUTO/ATW/INDOOR/OUTDOOR |
| AGC | Auto/Manual |
| BLC | ON/OFF |
| HLC | Support |
| WDR | ≥ 120 dB |
| Anti-shake | On / Off |
| Objektif Zamanı | PAL 1-1/10,000s |
| NTSC 1-1/10,000s |
| Gündüz ve Gece | ICR |
| Dijital Yakınlaştırma | 16x |
| Privacy Mask | 8 programmable privacy masks |
| Otomatik Odak | Auto / Semi-automatic / Manual |
| Lens |
| Odaksal Uzunluk | 5 mm to 75 mm, 15× Optical |
| Yakınlaştırma Hızı | Approx. 2.4 s (optical, wide to tele) |
| Field of View | Horizontal field of view 53.8° to 4.0° (wide to tele) |
| Vertical field of view 31.9° to 2.3° (wide to tele) |
| Diagonal field of view 60.4° to 4.6°(wide to tele) |
| Minimum Çalışma Mesafesi | 10-1500mm (Wide-Tele) |
| Aralık Açıklık | F 1.6 to F 3.5 |
| Pan & Tilt |
| Pan Range | 360°endless |
| Pan Hızı | Pan manual speed 0.1° to 100°/s |
| Pan preset speed 100°/s |
| Tilt Range | 5°~90° (Auto Flip ) |
| Tilt Hızı | Tilt manual speed 0.1° to 80°/s |
| Tilt preset speed 80°/s |
| Proportional Zoom | Rotation speed can be adjusted automatically according to zoom multiples |
| Number of Preset | 256 |
| Devriye | 10 patrols, up to 32 presets per patrol |
| Otomatik Tur | 5 patterns, with the total recording time no less than 10 minutes |
| Power-off Memory | Support |
| Park Action | Preset/Patrol/Pattern/Pan Scan/Tilt Scan/Panorama Scan/Day Mode/Night Mode/None |
| PTZ Pozisyonlama Gösterimi | ON/OFF |
| Alarm |
| Alarm Girişi | 2 |
| Alarm Çıkışı | 1 |
| Input & Output |
| Video Output | Switchable TVI/AHD/CVI/CVBS video output, (NTSC or PAL composite, BNC) |
| General |
| RS-485 Protocolleri | HIKVISION, Pelco-P, Pelco-D, self-adaptive |
| Language | English |
| Power Supply | 12V DC |
| Güç Tüketim | Max. 12 W |
| Çalışma Sıcaklığı / Nem oranı | -30 °C-65°C(-22°F-149°F) |
| 90% or less |
| Boyutlar | DS-2AE4215T-D3 (Indoor) Ø 165 mm × 179.5 mm (Ø 6.5" × 7.1") |
| DS-2AE4215T-D3 (In-ceiling) Ø 165 × 168 mm (Ø 6.5" × 6.6") |
| Ağırlık (yaklaşık) | 2 kg (4.41 Ib.) |
| Montaj Seçeneği | Various mounting modes optional |
