| Camera |
| Image Sensor : 1/3" Progressive Scan CMOS |
| Signal System : PAL/NTSC |
| Effective Pixels : 1920(H)*1080(V) |
| Min. Illumination : 0.01 Lux @(F1.2,AGC ON), 0 Lux with IR |
| Shutter Time : 1/25(1/30) s to 1/50,000 s |
| Lens : 3.6mm (2.8mm, 6mm, 8mm, 12mm, 16mm optional) |
| Angle of View : 80.9°(3.6mm), 103.5°(2.8mm), 54.3°(6mm), 38°(8mm), 24.3°(12mm), 18.9°(16mm) |
| Lens Mount : M12 |
| Adjustment Range : Pan: 0 - 360°, Tilt: 0 - 90°, Rotation: 0 - 360° |
| Day& Night : IR cut filter with auto switch |
| Video Frame Rate : 1080p @ 25fps/1080p @ 30fps |
| HD Video Output : 1 Analog HD output |
| Synchronization : Internal Synchronization |
| CVBS Output : 1Vp-p Composite Output(75Ω/RCA) |
| S/N Ratio : More than 52dB |
| Menu |
| Camera ID : On/off (15 characters, position programmable) |
| D/N Mode : Color/ BW/ EXT |
| Auto White Balance : ATW/ AWC-SET/ Indoor/ Outdoor/ Manual |
| Private Mask : On/Off, maximum 8 zones |
| Motion Detection : On/Off, maximum 4 zones |
| BLC : On/Off |
| AGC : Support |
| Anti-flicker : On/ Off |
| Language : English/ Japanese/ CHN1/ CHN2/ Korean/ German/ French/ Italian/ Spanish/ Polish/ Russian/ Portuguese/ Dutch/ Turkish/ Hebrew/ Arabic |
| Function : Eclipse, Digital noise reduction, Digital zoom(62x), Slow shutter, Mirror, Defog, Defect pixel correction, SMART D-ZOOM |
| Scene : Indoor, Outdoor, Indoor1, LOW-LIGHT |
| General |
| Operating Conditions : -30 °C ~ 60 °C (-22 °F ~ 140 °F) Humidity 90% or less (non-condensing) |
| Power Supply : 12 V DC±10% |
| Power Consumption : Max. 5.5W |
| Weather Proof : IP66 |
| IR Range : Up to 40m |
| Dimension : Φ114.6 × 89.1mm(Φ4.5” × 3.5”) |
| Weight : Net weight: 340 g (0.75 lb) |
| Shipping weight : 419 g (0.92 lb) |
