| Video System | NTSC / PAL (auto detection) |
| Video Sıkıştırma | H.264 |
| Video Girişi | 8 Kanal |
| Video Çıkışı | Main monitor output |
| Ses Giriş / Çıkışı | 4 audio inputs, 1 audio output (Mono) |
| Maximum Kayıt Hızı (Frame) | 704×480 pixels with 60 IPS / |
| 704×576 pixels with 50 IPS |
| Maximum Kayıt Hızı (Field) | 704×240 pixels with 120 IPS / |
| 704×288 pixels with 100 IPS |
| Maximum Kayıt Hızı (CIF) | 352×240 pixels with 240 IPS / |
| 352×288 pixels with 200 IPS |
| Ayarlanabilir Kayıt Hızı (Frame) | 60, 30, 15, 7 IPS / |
| 50, 25, 12, 6 IPS |
| Ayarlanabilir Kayıt Hızı (Field) | 120, 60, 30, 15 IPS / |
| 100, 50, 25, 12 IPS |
| Ayarlanabilir Kayıt Hızı (CIF) | 240, 120, 60, 30 IPS / |
| 200, 100, 50, 25 IPS |
| Multilingual OSD | YES |
| Image Quality Setting | Best, High, Normal and Basic |
| Hard Disk Storage | Accommodates 2 SATA HDDs (1 HDD capacity up to 1TB) |
| SATA Interface | Built-in |
| Quick Search | Time / Motion / Alarm search mode |
| Recording Mode | Manual / Timer / Motion / Alarm / Remote |
| Refresh Rate | 240 IPS for NTSC / 200 IPS for PAL |
| Multiplex Operation | Canlı Görüntüleme / 8 Kanal Kayıt |
| Oynatma (Eş Zamanlı 4 Kanal Oynatma) Yedekleme,Ağ İşlemleri |
| Remote Independent Operation | Fully remote independent operation |
| R.E.T.R. (Remote Event Trigger Recording) | YES |
| Motion Detection Area | 16 × 12 grids per camera for all channels |
| Motion Detection Sensitivity | One parameter with threesensitivity levels (High / Normal / Low) |
| Pre-alarm Recording | YES (8 MB) |
| Backup Device | USB 2.0 flash drive, Network |
| USB Interface | Front panel * 1 |
| Web Transmitting Compression Format | MPEG4 |
| Ethernet | 10/100 Base-T. Supports remote control and live view via Ethernet |
| Licensed software | “Video Viewer” / Internet Explorer or Mozilla Firefox |
| Web Interface | Supports licensed software “Video Viewer” / Internet Explorer & Mozilla Firefox web browsers / QuickTime (5 users access simultaneously) *Operating System: Windows Vista / XP / 2000; Apple Mac |
| Network Protocol | TCP/IP, PPPOE, DHCP and DDNS |
| IR Remote Control | YES (IR receiver built-in) |
| PTZ Control | YES |
| Dwell Time(Sequential Channel Switch) | Programmable with adjustable dwell time (3 / 5 / 10 / 15 seconds) |
| Alarm I/O | 8 inputs, 1 output |
| Picture Zoom | 2X digital zoom (Live & Playback) |
| Key Lock (Password Protection) | YES |
| Video Loss Detection | YES |
| Camera Başlığı | Supports up to 6 letters |
| Video Ayarı | Hue / Saturation / Contrast / Brightness |
| Date Display Format | YY/MM/DD, DD/MM/YY, MM/DD/YY, and Off |
| Daylight Saving | YES |
| Güç Kaynağı (±10%) | DC 19V |
| Güç Tüketimi (±10%) | ?64 W |
| Operating Temperature | 10? ~ 40? (50?~104?) |
| Boyutlar (mm)** | 430(W) x 65(H) x 338(D) |
| System Recovery | System auto recovery after power failure |
| Optional Peripherals | Keyboard controller |
