| Camera |
| Image Sensor : 1/2.9" 1Megapixel CMOS |
| Effective Pixels : 1280(H)×720(V) |
| Electronic Shutter : 1/50s~1/100,000s |
| Video Frame Rate : 25fps @ 720P |
| Synchronization : Internal |
| Mini. Illumination : 0.05Lux/F1.4, 0Lux IR on |
| Video Output : 1-channel BNC HDCVI high definition video output |
| Camera Features |
| Max. IR LEDs Length : 30m, Smart IR |
| Day/Night : Auto(ICR) / Color / B/W |
| Noise Reduction : 2D |
| Lens |
| Focal Length : 2.7~12mm |
| Angle of View : H: 93º~35º |
| Lens Type : Manual / Fixed Iris |
| Mount Type : Φ14 |
| General |
| Power Supply : DC12V±25% |
| Power Consumption : Max 3.2W |
| Working Environment : -30°C~+60°C / Less than 95%RH (no condensation) |
| Transmission Distance : Over 800m via 75-3 coaxial cable |
| Ingress Protection : IP67 |
| Dimensions(W×D×H) : 213mm×80mm×72mm |
| Weight : 0.55kg |
| Material : Metal |
