| Camera |
| Image Sensor |
1/2.8” STARVIS™ CMOS |
| Effective Pixels |
1920(H) x 1080(V), 2 Megapixels |
| Scanning System |
Progressive |
| Electronic Shutter Speed |
PAL: 1/3s~1/30,000s |
| NTSC: 1/4s~1/30,000s |
| Minimum Illumination |
Color: 0.005Lux@F1.6; 0Lux@F1.6 (IR on) |
| S/N Ratio |
More than 55dB |
| IR Distance |
Distance up to 150m (492ft) |
| IR On/Off Control |
Auto/Manual |
| IR LEDs |
4 |
| Lens |
| Focal Length |
4.8mm~120mm |
| Max. Aperture |
F1.6 ~ F4.4 |
| Angle of View |
H: 62.8° ~ 2.6° |
| Optical Zoom |
25x |
| Focus Control |
Auto/Manual |
| Close Focus Distance |
100mm~ 1000mm |
| PTZ |
| Pan/Tilt Range |
Pan: 0° ~ 360° endless; Tilt: -15° ~ 90°,auto flip 180° |
| Manual Control Speed |
Pan: 0.1° ~300° /s; Tilt: 0.1° ~200° /s |
| Preset Speed |
Pan: 400° /s; Tilt: 300° /s |
| Presets |
300 |
| PTZ Mode |
5 Pattern, 8 Tour, Auto Pan ,Auto Scan |
| Speed Setup |
Human-oriented focal Length/ speed adaptation |
| Power up Action |
Auto restore to previous PTZ and lens status after power failure |
| Idle Motion |
Activate Preset/ Scan/ Tour/ Pattern if there is no command in the specified period |
| Protocol |
DH-SD, Pelco-P/D (Auto recognition) |
| Video |
| Resolution |
1080P(1920×1080)/720P(1280×720) |
| Frame Rate |
25/30fps@1080P, 25/30/50/60fps@720P |
| Video Output |
1-channel BNC high definition video output/ CVBS standard definition video output (switchable) |
| Day/Night |
Auto(ICR) / Color / B/W |
| OSD Menu |
Support |
| Backlight Compensation |
BLC / HLC / WDR (120dB) |
| White Balance |
Auto,ATW,Indoor,Outdoor,Manual |
| Gain Control |
Auto / Manual |
| Noise Reduction |
Ultra DNR (2D/3D) |
| Digital Zoom |
16x |
| Flip |
180° |
| Privacy Masking |
Up to 24 areas |
| Certifications |
| Certifications |
CE: EN55032/EN55024/EN50130-4 |
| FCC: Part15 subpartB,ANSI C63.4- 2014 |
| UL: UL60950-1+CAN/CSA C22.2,No.60950-1 |
| Interface |
| Video Interface |
1 |
| Audio Interface |
1 channel in |
| RS485 |
1 |
| Alarm I/O |
2/1 |
| Electrical |
| Power Supply |
AC24V/3A(±10%) |
| Power Consumption |
13W,23W (IR on) |
| Environmental |
| Operating Conditions |
-40°C ~ 70°C (-40°F ~ +158°F) / Less than 90% RH |
| Ingress Protection |
IP66 |
| Vandal Resistance |
N/A |
| Construction |
| Casing |
Metal |
| Dimensions |
Φ186.0(mm) x 309(mm) |
| Net Weight |
3.9kg(8.60lb) |
| Gross Weight |
7.2kg(15.87lb) |
